Vivotek IB9389-EHV-V3 - cámara ip bullet exterior 5 mp, ir 40mts, real sight engine ia, wdr pro, micrófono integrado, lente fijo 2.8 mm, protección ip66, ik10, ciberseguridad trend micro, ia deep search, smart vca, di/do, ndaa
Precio especial $9,863.00 IVA incluido + Envio $150 MXN
Antes $11,441.00
Disponible 40 Pzas
Antes $11,441.00
Disponible 40 Pzas
sku: IB9389-EHV-V3
pub
MX0000108082
Vivotek IB9389-EHV-V3 5MP Outdoor Network Bullet Camera with Night Vision
Key Features
- 2560 x 1920 Resolution at 30 fps
- IR LEDs for Night Vision up to 131
- 2.8mm Fixed Lens
- 103.4° Horizontal Angle of View
- Two-Way Audio
- Supports microSD Cards up to 1TB
- RJ45 Ethernet with PoE Technology
- Complies with ONVIF Profiles G, S & T
- IP67 Rated for Outdoor Use
- IK10-Rated for Vandal Resistance
Securely monitor your surroundings with the IB9389-EHV-V3 5MP Outdoor Network Bullet Camera from Vivotek. This unit uses a 1/2.8' progressive scan CMOS sensor to capture 2560 x 1920 resolution video at 30 fps. Four IR LEDs provide up to 131 of night vision. The camera s 2.8mm fixed lens delivers a 103.4° horizontal angle of view. Two-way audio is possible thanks to a built-in microphone, along with an audio input and output. An onboard memory card slot accepts microSD/SDHC/SDXC cards up to 1TB (available separately). Integrated PoE technology simplifies connectivity by enabling the transfer of power and data through a single cable.
This camera complies with ONVIF profiles G, S, and T, making it compatible with a wide range of surveillance devices. It is housed in an IP66- and IK10-rated enclosure that is suitable for safe outdoor use in areas at high risk of vandalism.
Multimedia SoC CPU
Removable IR cut filter enables day and night functionality
ePTZ with 48x digital zoom
Built-in microphone picks up audio from up to 16 away
WDR Pro
Image settings include white balance, image adjustment (brightness, contrast, saturation, sharpness, gamma curve), defog, 3D-DNR, EIS (built-in gyro sensor), and scene mode (auto, deblur)
Exposure modes include BLC, HLC, exposure control (exposure level, iris adjustment, exposure time, gain control, iris mode), AE speed adjustment, and WDR
Video title and time stamp overlay, video orientation (flip, mirror, rotation), and day/night settings
Privacy masking
Analytics include Vision Object Analytics (people/vehicle classification/attribute extraction), five-window video motion detection, people detection, vehicle detection, time filter, and Smart VCA (intrusion detection, loitering detection, line crossing detection, unattended object detection, missing object detection, face detection, and crowd detection)
Live viewing for up to ten clients
3-year free trial of Trend Micro IoT Security (brute force attack event, cyberattack event, and quarantine event)
Compatible with Microsoft Windows 10, 8, and 7, macOS 10.12 (Chrome only), Chrome 58.0 or higher, and VLC 1.1.11 or higher
System power and status LED indicators
Specs
| Image Sensor |
1/2.8'-Type CMOS
|
| Focal Length |
2.8mm
|
| Field of View |
Horizontal: 103.4°
Vertical: 75.3° Diagonal: 135.2° |
| Built-In Microphone |
Yes
|
| Power I/O |
1x RJ45
|
Imaging
| Number of Lenses |
1
|
| Image Sensor |
1/2.8'-Type CMOS
|
| Sensor Resolution |
Effective: 5 Megapixel
|
| IR Cut Filter |
Yes
|
| Day/Night |
Yes
|
| DORI Coverage |
With 2.8mm Lens:
Detect: At 198.2 / 60.4 m Observe: At 79.1 / 24.1 m Recognize: At 39.4 / 12 m Identify: At 19.7 / 6 m |
Exposure Control
| Shutter Speed |
1/32000 to 1/5 Second
|
| Signal-to-Noise Ratio |
55 dB
|
| Minimum Illumination |
0.055 Lux (Color)
0 Lux (Black and White) |
Lens
| Focal Length |
2.8mm
|
| Max Digital Zoom |
48x
|
| Field of View |
Horizontal: 103.4°
Vertical: 75.3° Diagonal: 135.2° |
| Maximum Aperture |
f/2
|
Video
| Max IP Streaming |
H.264, H.265, MJPEG via RJ45
2560 x 1920 up to 30.00 fps 1920 x 1080 up to 60.00 fps |
| Multi-View Streaming |
Yes: 3 Streams
|
Control
| Camera Angle Adjustment |
Vertical: 0 to 80°
Rotation: 0 to 350° |
Networking
| Security |
Digest Authentication, HTTPS, IEEE 802.1X, Password Protection, User Access Log
|
| Supported Protocols |
ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, NTP, ONVIF Profile G, ONVIF Profile S, ONVIF Profile T, PPPoE, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SFTP, SMTP, SNMP v1/v2c/v3 (MIB-II), SSL/TLS, TCP, UDP, UPnP
|
Interface
| Media/Memory Card Slot |
Single Slot: microSD/microSDHC/microSDXC [1 TB Maximum]
|
| Other I/O |
1x RJ45
|
| 1- or 2-Way Audio |
Two-Way
|
| Audio Formats |
AAC-LC, G.711, G.726, MP2
|
| Built-In Microphone |
Yes
|
| Memory |
2 GB RAM / 8000 MB Flash
|
| External Storage Options |
NAS
|
System Integration
| Analytics |
Abandoned Object, Crowd Gathering, Face Detection, Intrusion Detection, Loitering, Motion Detection, Object Detection, Object Removal, People Detection, Vehicle Detection, Virtual-Line Crossing Detection
|
| Built-In Installation Aids |
Pixel Counter
|
Sensors & Alarms
| Event Trigger |
Yes
|
| Event Action |
Recording, Notification, Alarm
|
| Alarm I/O |
No
|
Power
| PoE Support |
PoE 802.3af
|
| Power I/O |
1x RJ45
|
| Power Consumption |
PoE: 12.4 W with IR On
PoE: 9.6 W with IR Off |
Environmental
| Operating Conditions |
-31 to 140°F / -35 to 60°C up to98% Humidity
|
| Impact Resistance |
Impact-Resistant (IK10)
|
| Environmental Resistance |
Dust/Weather/Water-Resistant (IP67)
|
| Startup Temperature |
-4 to 122°F / -20 to 50°C
|
General
| Certifications |
BIS, BSMI, CB, CE, EN, FCC, IC, ICES, IEC/EN, RCM, UKCA, UL, VCCI
|
| Illumination |
4x IR LEDs up to 131.2 / 40 m
|
| OS Compatibility |
Windows 7 to 10 / macOS 10.12 Only
|
| Dimensions (W x H x D) |
3.6 x 3.6 x 10.2' / 92 x 92 x 258.5 mm
|
| Weight |
2.27 lb / 1.03 kg (Body Only)
|
Packaging Info
| Package Weight |
3.1 lb
|
| Box Dimensions (LxWxH) |
15 x 6.7 x 6.7'
|
| Marca | Vivotek |
|---|---|
| MPN: | IB9389-EHV-V3 |
