Grandstream GWN7711P GWN7711P, switch administrable capa 2-lite, 8 x gigaeth, 4 poe, fuente 60w
Precio especial $1,403.00 IVA incluido + Envio $150 MXN
Antes $1,627.00
Disponible 48 Pzas
Antes $1,627.00
Disponible 48 Pzas
sku: GWN7711P
pub
MX0000106556
La serie GWN7711(P) son switches de red administrable Capa 2 que permiten a las pequeñas y medianas empresas crear redes empresariales escalables, seguras, de alto rendimiento e inteligentes que son fáciles de usar y administrar. Soporta VLAN para una segmentación del tráfico flexible y sofisticada, QoS para priorizar el tráfico de la red, IGMP Snooping para optimizar el rendimiento de la red y capacidades de seguridad integrales contra posibles ataques. El modelo PoE proporciona una salida PoE dinámica inteligente para alimentar teléfonos IP, cámaras IP, puntos de acceso Wi-Fi y otros dispositivos PoE, además el modelo PoE permite el modo de salida PoE pasiva de 24 VCC. La serie GWN7711(P) es fácil de administrar e implementar, incluida la interfaz de usuario web local del switch de la serie GWN7711(P) y GWN.Cloud. El método de instalación en escritorio y montaje en pared es adecuado para hoteles, oficinas en casa, pequeñas y medianas empresas y otros sectores similares. La serie GWN7711(P) son los switches de red administrable ideales para pequeñas y medianas empresas.
CARACTERÍSTICAS:
- 8 puertos Gigabit Ethernet
- Control de energía inteligente para permitir la asignación dinámica de energía PoE/PoE+ por puerto para los modelos PoE
- Cuenta con detección de bucle, prueba de cable y duplicación de puerto para localizar rápidamente fallas de red
- Indicadores LED. Por puerto: enlace/actividad/estado de energía PoE Por dispositivo: potencia
- Silencioso: Sin Ventilador
- Soporta gestión WEB conveniente e inteligente y gestión GWN.Cloud
- Control de tormentas de transmisión/multidifusión/unicast para monitorear los niveles de tráfico
- QoS integrado que permite priorizar el tráfico de red
GWN.CLOUD
Los switches serie GWN7711(P) puede ser administrados con GWN.Cloud, Servicio gratuito en la nube diseñado por Grandstream para ofrecer una plataforma de administración de redes WiFi segura y centralizada para cualquier número de puntos de acceso WiFi en cualquier cantidad de ubicaciones
*Datos en ingles
Grandstream GWN7711P Layer 2-Lite Managed Switch, 8 x GigE (4 x PoE/PoE+ or +24VDC Output. The GWN7711 series are Layer 2 Lite managed network switches that allow small-to-medium businesses to build scalable, secure, and smart business networks that are easy to use and cloud manageable.
They support VLAN for flexible and sophisticated traffic segmentation, QoS for prioritization of network traffic, IGMP Snooping for network performance optimization, and comprehensive security capabilities against potential attacks.
The GWN7711P provides 4 PoE ports for smart dynamic PoE output to power IP phones, IP cameras, Wi-Fi access points and other PoE endpoints. This PoE-capable model also supports 24V DC passive PoE-out mode.
The GWN7711 Series are easy to manage through the local web user interface and the cloud using the Grandstream Device Management System (GDMS). By supporting both desktop and wall mount installation, these Layer 2 Lite switches are suitable for hotels, home offices, small-to-medium businesses, and more. Thanks to a comprehensive suite of customizable switching features, available 24V DC passive PoE mode, and easy cloud management, the GWN7711 series are the ideal managed network switches for small-to-medium sized deployments.
They support VLAN for flexible and sophisticated traffic segmentation, QoS for prioritization of network traffic, IGMP Snooping for network performance optimization, and comprehensive security capabilities against potential attacks.
The GWN7711P provides 4 PoE ports for smart dynamic PoE output to power IP phones, IP cameras, Wi-Fi access points and other PoE endpoints. This PoE-capable model also supports 24V DC passive PoE-out mode.
The GWN7711 Series are easy to manage through the local web user interface and the cloud using the Grandstream Device Management System (GDMS). By supporting both desktop and wall mount installation, these Layer 2 Lite switches are suitable for hotels, home offices, small-to-medium businesses, and more. Thanks to a comprehensive suite of customizable switching features, available 24V DC passive PoE mode, and easy cloud management, the GWN7711 series are the ideal managed network switches for small-to-medium sized deployments.
Features
- 8 Gigabit Ethernet ports
- Smart power control to support dynamic PoE/PoE+ power allocation per port for the PoE models
- Supports Loop Detection, Cable Test and Port Mirror to quickly locate network faults
- Whisper Quiet: fan-less
- Convenient and intelligent management through the Web UI and the cloud (GDMS)
- Broadcast/Multicast/Unicast Storm Control to monitor traffic levels
- Built-in QoS allows for prioritization of network traffic
| Details | |
|---|---|
| Manufacturer s Code | GWN7711P |
| Network Protocol | IPv4, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at |
| Gigabit Ethernet Ports | 8 |
| PoE Out Ports | 4 |
| Power Supply | External 5VDC/0.6A External 48-53.5VDC/1.22A |
| PoE Output | Port 1-4 support 802.3af/at standard PoE out: Up to 30W per port PoE out, total 60W Power Budget, Port 1-4 support 24VDC Passive mode via UI, Port 1 (up to 30W): 24V 4 pair VH mode 1.3A, 4 pair VH mode Pins: 1,2,4,5 (+); 3,6,7,8 (-), Port 2-4 (up to 15W): 24V 2 pair mode, 0.65A, 2 pair normal mode Pins: 4,5 (+); 7,8 (-) |
| Max Total PoE Output Power | 60W |
| Maximum Output Power per PoE Port | 30W |
| Auxiliary Ports | 1x Reset Pinhole |
| Forwarding Mode | Store-and-forward |
| Total non-blocking throughput | 8Gbps |
| Switching Capability | 16Gbps |
| Jumbo Frame | 2K/3K/4K/5K/6K/7K/8//9K/12K/15K |
| Forwarding Mode | 11.9Mpps |
| Packet Buffer | 4Mb |
| MAC | 8K MAC address capacity, Support MAC address search |
| VLAN | 4K VLANs, Port-based VLAN, 802.1Q VLAN |
| LAG | 4 |
| Multicast | IGMP Snooping, Report Message Suppression |
| QoS | Auto prioritization of the incoming port of the packet, Priority Mapping, Queue scheduling, including SP, WRR, WFQ, Supports port priority, 802.1p priority and DSCP priority, Bandwidth control, Storm control, Rate limit |
| DHCP | DHCP client |
| Maintenance | Backup and restore, system reboot, factory reset, firmware upgrade, monitoring including port statistics, port mirroring, cable test and loop prevention, ping and pong watchdog |
| Security | Storm control, Port VLAN isolation, Filtering MAC adress, Kensington Security Slot (Kensington Lock) support |
| Mounting | Desktop/Wall-mount |
| LED Indicators | Per Port: Link/Activity - Green, GWN7711P Port 1-4: PoE power state - Yellow, Per Device: Power - Green |
| Environmental | Operating Temperature: 0 to 40 °C (32 to 104 °F), Storage Temperature: -20 to 60 °C (-4 to 140 °F), Operating Humidity: 10% to 90% Non-condensing, Storage Humidity: 10% to 90% Non-condensing |
| Dimensions | Unit: 190 x 100 x 28mm, Package: 230 x 210 x 51mm |
| Enclosure | Metal |
| Weight | Unit: 0.44kg, Entire Package: 0.92kg |
| Compliance | FCC, CE, RCM, IC |
| Marca | Otros |
|---|---|
| MPN: | GWN7711P |
