Bussmann FWH-150B eaton series fwh high speed fuse, 1000 vac, 800 vdc, 150a, 200 kaic at 50 500 none, blade end x end, stud
Precio especial $540.00 IVA incluido + Envio $150 MXN
Antes $626.00
Disponible 10 Pzas
Antes $626.00
Disponible 10 Pzas
sku: FWH-150B
pub
MX0000106343
FWH-150B
Eaton Bussmann series FWH high speed fuse, 1000 Vac, 800 Vdc, 150A, 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc, None, High speed fuse, Blade end X blade end, Stud
| General Specifications | |
|---|---|
| Product Name |
Eaton Bussmann series high speed cylindrical fuse
|
| Catalog Number |
FWH-150B
|
| UPC |
051712795845
|
| EAN |
5027590020855
|
| Product Length/Depth |
91 mm
|
| Product Height |
30 mm
|
| Product Width |
30 mm
|
| Product Weight |
154 g
|
| Compliances |
CE Marked
RoHS Compliant |
| Certifications |
UL Recognized
CSA Certified |
| Especificaciones del producto | |
| Amperage Rating |
150 A
|
| Breaking capacity |
200 kA
|
| Fuse indicator |
Non Indicating
|
| Insulated metal gripping lugs (IMGL) |
No
|
| Utilization category |
aR (accompanied semiconductor protection)
|
| Voltage type |
AC/DC
|
| Rated switching capacity |
200 kA
|
| Rated voltage AC |
500 V
|
| Rated voltage DC |
500 V
|
| Mounting dimension |
M8
|
| Center-to-center distance of connections |
74.09 mm
|
| Current type |
AC/DC
|
| Class |
Class aR
|
| Clearing (I2T) |
4600
|
| Watt losses |
30 W
|
| Fuse shape |
Center bolted tags
|
| Pre arc (I2T) |
1100
|
| Color |
None
|
| Interrupt rating |
50 kAIC at 500 Vdc
200 kAIC at 1000 Vac |
| Connection |
Blade end x blade end
|
| Construction size |
Other
|
| Mounting method |
Stud
|
| Voltage rating |
500 Vac, 500 Vdc
|
| Type |
High speed fuse
|
| Application |
Semiconductor, DC Common bus, DC drives, Power converters/rectifiers
|
| Fuse type |
FWH-B
|
| Fuse system (according to IEC 60269) |
Other
|
| Marca | Otros |
|---|---|
| MPN: | FWH-150B |
