A Safer Way to Engage
Show off content in fine detail with the 4K UHD resolution. Plus, germ-resistant screens coated with a proprietary nano-ionic silver formula ensure long-lasting protection against common germs. Boasting 99.9% efficacy, this coating is certified by TÜV Rheinland.
Attract More Attention
With detailed 4K UHD images, an anti-glare screen, 9H tempered glass, and touch functionality, the IL01 Series is an optimal interactive signage solution for business applications.
Crystal Clear Images
Providing ample detail, the 4K UHD display boasts an anti-glare screen for easy readability. Furthermore, a 400 nits brightness means this display can be easily seen in indoor environments.
Display it Your Way
Display the IL01 Series in landscape or portrait mode to get the best fit for your business. Plus, the 0.65' slim bezel is designed to fit a wide range of installation environments.
Effortless Content Creation
Choose from a growing gallery of digital signage templates to easily create interactive content for your brand; get access to Pantone digital colors for true-to-life images.
Centralized Management
Manage all your content remotely with X-Sign. You can easily schedule promotions on multiple displays and receive usage reports to better understand customer preferences.
Convenient Display Management
Managing your displays has never been more convenient. BenQ s ecosystem makes it easy for you to monitor and update all your devices at any time, from any location.
Device Management Solution (DMS)
Centrally manage all your displays from the comfort of your desk with BenQ s Device Management Solution (DMS). Install apps, monitor devices, and update multiple displays all at once.
Always Up to Date
Ensure all your BenQ displays are equipped with the latest features and security patches with over-the-air (OTA) updates.
Key Specs
| Display Size |
55'
|
| Native Resolution |
3840 x 2160
|
| Maximum Brightness |
400 nits / cd/m2
|
| Touchscreen |
Yes, Infrared (IR)
|
| Inputs |
1x DE-15/DB-15 (VGA)
2x HDMI 2.0 1x DisplayPort 1.2 1x 1/8' / 3.5 mm (Analog Audio) |
| Outputs |
1x HDMI 2.0
1x 1/8' / 3.5 mm (Analog Audio) 1x TOSLINK Optical (Digital Audio) |
| USB I/O |
2x USB-A 2.0
1x USB-B 2.0 (Touchscreen Control) |
| Ethernet I/O |
2x RJ45 10/100 Mb/s Ethernet
|
| Other I/O |
1x Unspecified Connector Type Serial (RS-232C)
|
| Built-In Speakers |
Yes, 2x 10 W
|
Display
| Display Size |
55'
|
| Panel Type |
IPS-Type LCD
|
| Aspect Ratio |
16:9
|
| Display Orientation |
Landscape, Portrait
|
| Native Resolution |
3840 x 2160
|
| Maximum Brightness |
400 nits / cd/m2
|
| HDR Support |
No
|
| Contrast Ratio |
1300:1
|
| Response Time |
9 ms
|
| Refresh Rate |
60 Hz
|
| Color Support |
1.07 Billion Colors (10-Bit)
|
| Color Gamut |
68% NTSC
|
Surface
| Touchscreen |
Yes, Infrared (IR)
|
| Multi-Touch Points |
40
|
| Hardness Rating |
9H
|
Video
| TV Tuner |
No
|
Connectivity
| Inputs |
1x DE-15/DB-15 (VGA)
2x HDMI 2.0 1x DisplayPort 1.2 1x 1/8' / 3.5 mm (Analog Audio) |
| Outputs |
1x HDMI 2.0
1x 1/8' / 3.5 mm (Analog Audio) 1x TOSLINK Optical (Digital Audio) |
| HDCP Support |
Yes
|
| NFC |
No
|
| USB I/O |
2x USB-A 2.0
1x USB-B 2.0 (Touchscreen Control) |
| Ethernet I/O |
2x RJ45 10/100 Mb/s Ethernet
|
| Other I/O |
1x Unspecified Connector Type Serial (RS-232C)
|
| Number of OPS/Expansion Slots |
1
|
| Ambient Light Sensor |
No
|
| Multi-Input Support (PIP/PBP) |
No
|
Speaker
| Built-In Speakers |
Yes, 2x 10 W
|
| Speaker Configuration |
2-Channel
|
Hardware
| Smart TV |
Yes, Android 8.0
|
| CPU |
Quad-Core:
Cortex A73 (2 Cores) Cortex A53 (2 Cores) |
| Storage |
32 GB
|
| RAM |
3 GB
|
| Built-In Mic |
No
|
Electrical
| Power Consumption |
Typical: 111.0 W
|
| Input Power |
100 to 240 VAC, 50 / 60 Hz
|
General
| Operating Conditions |
32 to 104°F / 0 to 40°C at 20 to 85% Humidity
|
| Storage Conditions |
14 to 140°F / -10 to 60°C at 10 to 90% Humidity
|
| Certifications |
TUV
|
| VESA Mounting-Hole Pattern |
400 x 400 mm
|
| Lighting Lifespan |
50000 Hours
|
| Environmental Resistance |
No
|
| Impact Resistance |
No
|
| Lock Slot |
No
|
| Bezel Thickness |
16.6 mm
|
| Duty Cycle |
24 Hours / 7 Days
|
| Dimensions |
50.6 x 29.7 x 3.6' / 128.5 x 75.4 x 9.1 cm
|
| Weight |
64.2 lb / 29.1 kg
|
Packaging Info
| Package Weight |
84 lb
|
| Box Dimensions (LxWxH) |
55 x 33.25 x 7'
|
