Eaton FWP-70B fusible ultrarrápido de navajas, 700vca/vcd
Precio especial $1,533.00 IVA incluido + Envio $150 MXN
Antes $1,778.00
Disponible 6 Pzas
Antes $1,778.00
Disponible 6 Pzas
sku: FWP-70B
pub
MX0000105835
FWP-70B
Eaton Bussmann series FWP high speed fuse, 250 Vac/dc, 70A, 200 kAIC Vac, 50 kAIC at 700 Vdc, None, High speed fuse, Blade end X blade end, Stud
General Specifications | |
---|---|
Product Name |
Eaton Bussmann series high speed cylindrical fuse
|
Catalog Number |
FWP-70B
|
UPC |
051712796019
|
EAN |
5027590021821
|
Product Length/Depth |
112 mm
|
Product Height |
25 mm
|
Product Width |
25 mm
|
Product Weight |
108 g
|
Compliances |
CE Marked
RoHS Compliant |
Certifications |
UL Recognized
CSA Certified |
Especificaciones del producto | |
Type |
High speed fuse
|
Application |
Semiconductor, DC Common bus, DC drives, Power converters/rectifiers
|
Amperage Rating |
700 A
|
Breaking capacity |
200 kA
|
Fuse indicator |
Non Indicating
|
Insulated metal gripping lugs (IMGL) |
No
|
Utilization category |
aR (accompanied semiconductor protection)
|
Voltage type |
AC/DC
|
Rated switching capacity |
200 A
|
Rated voltage AC |
700 V
|
Rated voltage DC |
700 V
|
Mounting dimension |
M8
|
Center-to-center distance of connections |
91.5 mm
|
Current type |
AC/DC
|
Class |
Class aR
|
Clearing (I2T) |
2000 at 700 V
|
Watt losses |
18 W
|
Fuse shape |
Center bolted tags
|
Pre arc (I2T) |
305
|
Color |
None
|
Interrupt rating |
50 kAIC at 700 Vdc
200 kAIC Vac |
Connection |
Blade end x blade end
|
Construction size |
Other
|
Mounting method |
Stud
|
Packaging type |
Standard
|
Voltage rating |
700 Vac, 700 Vdc (UL)
|
Fuse type |
FWP-B
|
Fuse system (according to IEC 60269) |
Other
|
Marca | Eaton |
---|---|
MPN: | FWP-70B |
