Eaton BH-0111 portafusible modular para fusibles ultrarapidos 700vca
Precio especial $1,474.00 IVA incluido + Envio $150 MXN
Antes $1,710.00
Disponible 3 Pzas
Antes $1,710.00
Disponible 3 Pzas
sku: BH-0111
pub
MX0000105834
BH-0111
Fuse Block, Modular, 0-100A, 0-700V, High temperature thermoplastic material, 1-1/4 in-20 TPI stud connection, 14 to 2/0 AWG (copper) wire size
| General Specifications | |
|---|---|
| Product Name |
Eaton Bussmann series high speed square body fuse
|
| Catalog Number |
BH-0111
|
| UPC |
051712350518
|
| EAN |
5027590539357
|
| Product Length/Depth |
6.41 in
|
| Product Height |
2.68 in
|
| Product Width |
2.12 in
|
| Product Weight |
0.6 lb
|
| Compliances |
Contact factory
RoHS Compliant |
| Especificaciones del producto | |
| Type |
Modular
|
| Application |
Solid State Control Circuits, VFDs, UPS Systems
|
| Amperage Rating |
0-100A
|
| Connection |
1-1/4 inch - 20 TPI stud
|
| Wire size |
#14-2/0 AWG Cu
|
| Material |
High temperature thermoplastic
|
| Voltage rating |
0-700 V
|
| Marca | Eaton |
|---|---|
| MPN: | BH-0111 |
