Bussman BSPH3600YPV spd surge arrestor

Precio especial $5,689.00 IVA incluido + Envio $150 MXN
Antes $6,599.00
Disponible 1 Pzas
sku: BSPH3600YPV
pub
MX0000103865
Precios sujetos a cambios sin previo aviso
Pagos 100% seguros
Entrega Aprox.
Envio Nacional | Condicion: Nuevo
Logo

BSPH3600YPV

Eaton Cooper Power series stud, 600 Vdc 3 Pole Y Configuration SPD

General specifications

Product Name Eaton Bussmann series BSPM series surge arrestor
Catalog Number BSPH3600YPV
UPC 051712293945
Product Length/Depth 3.9 in
Product Height 2.3 in
Product Width 3 in
Product Weight 0.1 lb
Compliances CE Marked
RoHS Compliant
Certifications UL Recognized

Product specifications

Type Modular, without remote signaling contact
Special features Technology type hybrid
Application Photovoltaic systems
Nominal Discharge Current 20 kA
Voltage rating 600 Vdc
Class Class gG/gL
Operating temperature -40 to 80 °C
Mounting Method 35 mm DIN rail
Material Thermoplastic
Service response time 25 ns
Más información
MarcaBussman
MPN:BSPH3600YPV
