Bussman BSPH3600YPV spd surge arrestor
Precio especial $3,715.00 IVA incluido + Envio $150 MXN
Antes $4,309.00
Disponible 1 Pzas
Antes $4,309.00
Disponible 1 Pzas
sku: BSPH3600YPV
pub
MX0000103865
BSPH3600YPV
Eaton Cooper Power series stud, 600 Vdc 3 Pole Y Configuration SPD
General specifications |
|
| Product Name | Eaton Bussmann series BSPM series surge arrestor |
| Catalog Number | BSPH3600YPV |
| UPC | 051712293945 |
| Product Length/Depth | 3.9 in |
| Product Height | 2.3 in |
| Product Width | 3 in |
| Product Weight | 0.1 lb |
| Compliances | CE Marked RoHS Compliant |
| Certifications | UL Recognized |
Product specifications |
|
| Type | Modular, without remote signaling contact |
| Special features | Technology type hybrid |
| Application | Photovoltaic systems |
| Nominal Discharge Current | 20 kA |
| Voltage rating | 600 Vdc |
| Class | Class gG/gL |
| Operating temperature | -40 to 80 °C |
| Mounting Method | 35 mm DIN rail |
| Material | Thermoplastic |
| Service response time | 25 ns |
| Marca | Bussman |
|---|---|
| MPN: | BSPH3600YPV |
