Bussman FWA-4000AH fusible ultra rápido para pernos roscados 130vcavcd
Precio especial $13,460.00 IVA incluido + Envio $150 MXN
Antes $15,614.00
Disponible 6 Pzas
Antes $15,614.00
Disponible 6 Pzas
sku: FWA-4000AH
pub
MX0000103639
FWA-4000AH
Eaton Bussmann series FWA high speed fuse, 500 Vac/dc (35-800A only), 4000A, 200 kAIC Vac, 50 kAIC at 120 Vdc, None, High speed fuse, Flush, Stud
General specifications |
|
| Product Name | Eaton Bussmann series high speed cylindrical fuse |
| Catalog Number | FWA-4000AH |
| UPC | 051712795531 |
| EAN | 5027590020442 |
| Product Length/Depth | 48 mm |
| Product Height | 88.9 mm |
| Product Width | 88.9 mm |
| Product Weight | 3.35 g |
| Compliances | CE Marked RoHS Compliant |
| Certifications | UL Recognized |
Especificaciones del producto |
|
| Type | High speed fuse |
| Application | Semiconductor, DC Common bus, DC drives, Power converters/rectifiers |
| Amperage Rating | 4000 A |
| Breaking capacity | 200 kA |
| Fuse indicator | Non Indicating |
| Insulated metal gripping lugs (IMGL) | No |
| Utilization category | aR (accompanied semiconductor protection) |
| Voltage type | AC/DC |
| Rated switching capacity | 200 A |
| Rated voltage AC | 130 V |
| Mounting dimension | Other |
| Center-to-center distance of connections | 47.6 mm |
| Current type | AC |
| Class | Class aR |
| Clearing (I2T) | 9200000 |
| Watt losses | 257 W |
| Fuse shape | Cylindrical, flush end |
| Pre arc (I2T) | 3400000 |
| Color | None |
| Interrupt rating | 50 kAIC at 120 Vdc 200 kAIC Vac |
| Construction size | Other |
| Mounting method | Flush Stud |
| Packaging type | Standard |
| Voltage rating | 130 Vac, 130 Vdc |
| Fuse type | FWA-AH |
| Fuse system (according to IEC 60269) | IEC 60269-4 flush end connections type B |
| Marca | Bussman |
|---|---|
| MPN: | FWA-4000AH |
