Dahua DH-PSDW81642M-A360-D440-S3 cámara ip hubble wizmind ptz panorámica de 360° y multisensor 16 mp/ 8 sensores / 40x/ 400 m/ protección perimetral/ metadatos vídeo/ reconocimiento facial smart tracking/ h265+/h264+/ ranura para micro sd.
Precio especial $116,904.00 IVA incluido + Envio $150 MXN
Antes $135,609.00
Disponible 0 Pzas
Antes $135,609.00
Disponible 0 Pzas
Agotado
pub
MX0000103555
PSDW81642M-A360-D440-S3
16 MP Multi-Sensor 360° Panoramic PTZ Hubble WizMind Network Camera
> Channel 1 (Panoramic): 8 × 2 MP 1/1.8' CMOS image sensors. Field of View:Horizontal: 1 × 360°, Vertical: 103°. Channel 2 (PTZ): 1 × 4 MP 1/1.8' CMOS image sensors.
> Channel 2 (PTZ): 40x optical zoom, 16x digital zoom.
> Channel 2 (PTZ): Illumination distance up to 400 m.
> Channel 1 (Panoramic): Three switchable intelligent resources: Perimeter protection, Crowd map, Vehicle density.
> Channel 2 (PTZ): Three switchable intelligent resources: Perimeter protection, Video metadata, Face recognition.
> AR panorama technology; various AR tags can be overlaid.
> Smart tracking. GPS/BDS positioning.
> Smart H265+/H264+ encoding.
> WDR, 3D NR, HLC, BLC, applicable to various monitoring scenes.
> Alarm: 7 in, 3 out; audio: 2 in, 2 out; 1 channel BNC, 1 channel RS–485 (baud rate can be set). supports max. 512 G SD card.
| Camera | |
| Image Sensor | Channel 1 (Panoramic): 1/1.8' 2 Megapixel progressive CMOS Channel 2 (PTZ): 1/1.8' 4 Megapixel progressive CMOS |
| Pixel | Channel 1 (Panoramic) : 16 MP Channel 2 (PTZ): 4 MP |
| Max. Resolution | Channel 1 (Panoramic): 8192 (H) × 1800 (V) Channel 2 (PTZ): 2560 (H) × 1440 (V) |
| ROM | Channel 1 (Panoramic): 8 GB Channel 2 (PTZ): 8 GB |
| RAM | Channel 1 (Panoramic): 4 GB Channel 2 (PTZ): 2 GB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | Channel 1 (Panoramic): 0.0005 lux@F1.0 (Color,30 IRE) 0.0001 lux@F1.0 (B/W,30 IRE) Channel 2 (PTZ): 0.001 lux@F1.4 (Color,30 IRE) 0.0005 lux @F1.4(B/W,30 IRE); 0 lux (Illuminator on) |
| S/N Ratio | >56 dB |
| Illumination Distance | Channel 1 (Panoramic): No Channel 2 (PTZ): Up to 400 m (1312.34 ft) |
| Illuminator On/Off Control | Auto; Manual; Zoomprio |
| Illuminator Number | Channel 1 (Panoramic): No Channel 2 (PTZ): 7 (IR LED) |
| Pan/Tilt/Rotation Range | Pan: 0° to 360° Tilt: -11° to 90° |
| Built-in Battery | Channel 1 (Panoramic): Horizontal welding/lithium battery/3 V Channel 2 (PTZ): Horizontal welding/lithium battery/3 V |
| Lens | |
| Lens Type | Channel 1 (Panoramic) : Fixed-focal Channel 2 (PTZ): Vari-focal |
| Lens Mount | Channel 1 (Panoramic) : M16 Channel 2 (PTZ): Module |
| Focal Length | Channel 1 (Panoramic) : 2.8 mm Channel 2 (PTZ): 5.5 mm–220 mm |
| Max. Aperture | Channel 1 (Panoramic) : F1.0 Channel 2 (PTZ): F1.4 |
| Field of View | Channel 1 (Panoramic): H: 360° V: 103° Channel 2 (PTZ): H: 2.2°–61.8° V: 1.3°–36.3° D: 2.4°–69.2° |
| Iris Control | Channel 1 (Panoramic): No Channel 2 (PTZ): P-iris |
| Close Focus Distance | Channel 1 (Panoramic): 1.4 m (4.59 ft) Channel 2 (PTZ): 0.5 m–2 m (1.64 ft–6.56 ft) (T to W) |
| Smart Event | |
| IVS | Channel 1 (Panoramic): Yes Channel 2 (PTZ): Yes |
| Intelligence | |
| Intelligence Description | Channel 1 (Panoramic): Perimeter protection, crowd map, vehicle density. Channel 2 (PTZ): Perimeter protection, video metadata, face recognition |
| IVS (Perimeter Protection) | Channel 1 (Panoramic): Tripwire; intrusion; parking detection Channel 2 (PTZ):Tripwire; intrusion; parking detection;crossing virtual fence, fast moving, abandoned object, missing object, crowd gathering, loitering detection |
| Face Recognition | Channel 1 (Panoramic): No Channel 2 (PTZ): Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority and optimization snapshot) Supports adding 5 group face databases; registering person one by one or in batches; setting face similarity; and supports face comparison with the face database containing up to 10,000 face pictures |
| Vehicle Density | Channel 1 (Panoramic):Vehicle density; parking upper limit; traffic congestion alarm Channel 2 (PTZ): No |
| Crowd Distribution Map | Channel 1 (Panoramic):Crowd map, global crowd density; crowd density in area; people counting in area; Channel 2 (PTZ): No |
| Video Metadata | Channel 1 (Panoramic): No Channel 2 (PTZ): Motor vehicle, non-motor vehicle, face, and human body detection; snapshot; snapshot optimization; optimal face snapshot upload. Motor vehicle attributes: License plate, plate color, vehicle type, vehicle color, vehicle logo, vehicle model/year, sun visor, seatbelt., smoking, calling, ornament, and annual inspection sticker. Non-motor vehicle attributes: Type, vehicle color, number of people, top type and color, and hat. Human body attributes: Top and bottom type and color, bag, hat, gender, and umbrella. Face attributes: Gender, age, expressions, glasses, face mask, and bread |
| Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Video | |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec | Smart H.264+ Smart H.265+ |
| Video Frame Rate | Channel 1 (Panoramic) : Main stream: 8192 × 1800 @(1–25/30 fps) sub stream: 2048 × 452 @ (1–25/30 fps) third stream: 3840 × 832 @ (1–25/30 fps) Channel 2 (PTZ): Main stream: 2560×1440@ (1–25/30 fps) sub stream: 704×576@ (1–25/30 fps) third stream:1920×1080@ (1–25/30 fps) |
| Stream Capability | 3 streams |
| Resolution | Channel 1 (Panoramic) : Main stream: 8192 × 1800; 7680 × 1680; 5760 × 1264; 4096 × 900 sub stream: 2048 × 452 third stream: 3840 × 832; 2560 × 560 Channel 2 (PTZ): Main stream: 2560 × 1440; 1920 × 1080; 1280 × 960; 1280 × 720 sub stream: 704 × 576; 640 × 480; 352 × 288 third stream: 1920 × 1080; 1280 × 960; 1280 × 720 |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | Channel 1 (Panoramic): H.264: 96 Kb/s–32768 Kb/s H.265: 38 Kb/s–29362 Kb/s Channel 2 (PTZ): H.264: 32 Kb/s–15872 Kb/s H.265: 12 Kb/s–9472 Kb/s |
| Day/Night | Channel 1 (Panoramic): No Channel 2 (PTZ): ICR |
| BLC | Yes |
| HLC | Yes |
| WDR | Channel 1 (Panoramic): DWDR Channel 2 (PTZ): 120 dB |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Auto; Manual |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Default Bit Rate with Default Resolution | Channel 1 (Panoramic): 6144 kb/s (8192 × 1800) Channel 2 (PTZ): 6144 kb/s (2560 × 1440) |
| Region of Interest (RoI) | Channel 1 (Panoramic) : Yes (4 areas) Channel 2 (PTZ): Yes (8 areas) |
| Image Stabilization | Channel 1 (Panoramic): No Channel 2 (PTZ): No |
| Defog | Channel 1 (Panoramic): No Channel 2 (PTZ): Optical defog |
| Privacy Masking | Channel 1 (Panoramic) : 4 areas Channel 2 (PTZ): 24 areas (8 for each preset) |
| Image Correction | Channel 1 (Panoramic): No Channel 2 (PTZ): No |
| Audio | |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; G.723, G.711a by default |
| Audio Sampling | 8 kHz; 16 kHz; 32 kHz; 48 kHz; 64 kHz |
| Alarm | |
| Alarm Event | Channel 1 (Panoramic): External alarm; No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; voltage detection; motion detection; video tampering; scene changing; audio detection; intensity change; tripwire; intrusion; parking detection; crowd density; traffic congestion; parking upper limit Channel 2 (PTZ): Tripwire; intrusion; parking detection;crossing virtual fence, fast moving, abandoned object, missing object, crowd gathering, loitering detection; face recognition; video metadata |
| Network | |
| Network Port | RJ-45 (10/100/1000 Base-T) |
| SDK and API | Yes |
| Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P |
| Interoperability | ONVIF (Profile S/Profile G/ Profile T); CGI |
| User/Host | 20 (Total bandwidth: 400 M) |
| Storage | FTP; SFTP; Micro SD card (support max. 512 GB); NAS; SMB |
| Browser | IE: IE11 Chrome Firefox |
| Management Software | SmartPSS Lite; DSS |
| PTZ | |
| Pan/Tilt Range | Pan: 0° to 360° endless Tilt: –11° to 90°, auto flip 180° |
| Manual Control Speed | Pan: 240°/s Tilt: 100°/s |
| Telephoto Speed Limit | Yes |
| Positioning Accuracy | Pan: 0.1° Tilt: 0.1° |
| Positioning Accuracy Automatic Calibration | Yes |
| Remote Lens Reset | Yes |
| Remote PTZ Reset | Yes |
| Preset | 300 |
| Tour | 8 (up to 32 presets per tour) |
| Pattern | 5 |
| Scan | 5 |
| Power-off Memory | Yes |
| Idle Motion | Preset; Pattern; Tour; Scan |
| Time Task | Yes |
| 3D Positioning | Yes |
| PTZ Limit | Yes |
| Position Display | Yes |
| Information Display | Yes |
| Time Display | Yes |
| PTZ Restart | Yes |
| Certification | |
| Certifications | CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Port | |
| RS-485 | 1 (baud rate range:1200 bps–115200 bps) |
| Audio Input | 2 channels (terminal) |
| Audio Output | 2 channels (terminal) |
| Alarm Input | 7 channels in: 5mA 3V–5V DC |
| Alarm Output | 3 channels out: 1,000mA 30V DC/500mA 50V AC |
| Analog Output | 1 channel (CVBS output: BNC) |
| Power | |
| Operating Voltage | 36 VDC (±50%) |
| Power Supply | 36 VDC |
| Power Consumption | Basic: 59 W (36 VDC) Max. (Basic power consumption + WDR + intelligence on + IR on + PTZ operation ): 99 W (36 VDC) |
| Environment | |
| Operating Temperature | –40 °C to +70 °C (–40 °F to +158 °F) |
| Operating Humidity | ≤95% |
| Storage Temperature | –40 °C to +70 °C (–40°F to +158°F) |
| Storage Humidity | ≤95% |
| Protection | IP66 |
| Structure | |
| Casing | Metal + plastic |
| Product Dimensions | Φ383 mm × 462 mm (15.08' × Φ18.19') |
| Packaging Dimensions | 500 mm × 500 mm × 658 mm (19.69' × 19.69' × 25.91') (L × W × H) |
| Net Weight | 14.4 kg (31.75 lb) |
| Gross Weight | 20.3 kg (44.75 lb) |
| Installation | Wall mount; ceiling mount; pole mount |
| Power Adapter | Included |
| Lens | Included |
| Power Output | NA |
| Marca | Dahua |
|---|---|
| MPN: | DH-PSDW81642M-A360-D440-S3 |
