Kramer 60-000590 kds-en7 - codificador avoip de alto rendimiento 4k60 sobre ethernet
Precio especial $18,378.00 IVA incluido + Envio $150 MXN
Antes $21,318.00
Disponible 4 Pzas
Antes $21,318.00
Disponible 4 Pzas
sku: 60-000590
pub
MX0000103243
El codificador KDS−EN7 ofrece transmisión de alta calidad de señales HDMI 4K@60Hz (4:2:0) a través de Ethernet. Además de las señales HDMI, se transmiten señales USB, infrarrojas, RS-232 y CEC. Excelente experiencia de usuario: amplia gama de interfaces. Preconfigurado para KM/KVM: menú OSD con encendido
El codificador KDS−EN7 ofrece transmisión de alta calidad de señales HDMI 4K@60Hz (4:2:0) a través de Ethernet. Además de las señales HDMI, se transmiten señales USB, infrarrojas, RS-232 y CEC.
- Excelente experiencia de usuario: amplia gama de interfaces. Preconfigurado para KM/KVM: menú OSD con modos de configuración para KM o para conmutación KVM totalmente configurable. Admite grandes instalaciones de videowall, hasta 16x16. Cambio rápido: 1 segundo.
- Ideal para instalaciones grandes. Altamente escalable: admite hasta 999 canales. Gestión de última generación mediante KDS-7-MNGR. Opciones de control flexibles: API abierta estándar Kramer Protocol 3000, pantalla LCD para configuración.
- Seguridad sólida: seguridad de TI de nivel empresarial: 802.1x y HTTPS/TLS. Seguridad certificada: certificado OWASP Top 10. Interfaces Ethernet separadas para transmisión y control. Arquitectura HW moderna para actualizaciones de firmware sólidas.
- Fácil planificación e instalación: — Rentable desde el principio. Gama de productos completa para cada aplicación. Plug & Play con conmutadores AVoIP Netgear M4250, Kramer Control, KDS-USB2, etc.
- Soporte PoE – consumo de energía – hasta 13 vatios
- Salida de bucle y conmutación integrada: salida de bucle HDMI en el codificador y entrada HDMI en el decodificador.
- Audio analógico: incrustación y desincrustación
- Puerta de enlace de control: utilice el protocolo 3000 para controlar dispositivos conectados a los codificadores o decodificadores mediante infrarrojos, RS-232 o CEC.
60-000590
Kramer KDS-EN7 - Streaming video encoder
| Specifications | |
|---|---|
| Dimensions & Weight / Depth | 14.5 cm |
| Dimensions & Weight / Height | 2.76 cm |
| Dimensions & Weight / Weight | 670 g |
| Dimensions & Weight / Width | 18.9 cm |
| Header / Brand | Kramer |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 17.9 cm |
| Shipping Height | 7.6 cm |
| Shipping Weight | 930 g |
| Shipping Width | 31.2 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| General | |
| Depth | 14.5 cm |
| Height | 2.76 cm |
| Type | Streaming video encoder |
| Weight | 670 g |
| Width | 18.9 cm |
| Power | |
| Low Voltage Power | DC 24 V |
| Power Consumption | 6 Watt |
| Studio & Production Equipment | |
| Features | Power Over Ethernet support, HDCP 2.2 compliant, scaler function |
| Terminals | |
| Terminals |
|
Kramer KDS-EN7 | 3840x2160 JPG 2000 1GbE Transmitter (Tx)
60-000590
High–performance, highly–scalable, AVoIP Encoder for 4K60 4:2:0, HDR10 over 1G network
- Outstanding end–user experience
- Ideal for large–scale deployments
- Robust security
- Simple planning and rollout
KDS−EN7 encoder is an advanced transmitter for streaming 4K@60Hz (4:2:0) video signals via Ethernet over copper cable. It encodes and streams over an IP network from HDMI input, and transmits the USB, IR, RS232, or CEC signal over IP network.
Outstanding end–user experience
- Rich set of inputs and interfaces
- Easy–to–use KM/KVM — Searchable OSD Menu for KM and fully configurable KVM roaming
- Large scale video wall — up to 16x16
- Instantaneous switching time — 1 second
Ideal for large–scale deployments
- Highly scalable — 999 channels build in support
- State of the art management device
- Rich set of management capabilities — Standard P3K Open API , LCD screen for configuration
Robust security
- Enterprise IT–grade security — 802.1x and HTTPS/TLS
- Security certification — OWASP Top 10 certificate
- Separate ETH ports for optimal security and experience
- New HW architecture that enables robust FW update
Simple planning and rollout:
- Cost–effective from day one
- Full product range for any site, any application
- Plug–and–play with Netgear M4250 AVoIP switches, Kramer Control, KDS–USB2, etc.
PoE Support
- Using PoE switch — up to 13W consumption
Alternative sources/destinations
- HDMI Loop–Through on Encoder and HDMI Input on Decoder
Analog Audio
- Embedding and De–embedding
**Control gateway **
- Through P3K control/communicate with IR, RS232, or CEC to the connected devices
Applications:
- For real–time essential installations such as command and control rooms
- For large scale AV content sharing installations using existing wires and infrastructure in corporate offices and government applications
- AV distribution systems with one or more sources and many displays in schools, universities, and public venues
- For AV installations where low latency KM/KVM capabilities are required
| Informacion tecnica | |
|---|---|
| General | |
| Extender type | |
| Extender type | Transmitter (Tx) |
| Technology | JPG 2000 |
| Video specifications | |
| Max supported resolution | |
| Max supported resolution | 3840x2160 |
| Refresh rate | 60 Hz |
| Chroma subsampling (4K) | 4:2:0 |
| Scaler | No |
| Video operation modes | Videowall/Tileing Up to 16x16 displays (Decoder) |
| Connections | |
| Video in | |
| Video in | HDMI With CEC |
| Video out | HDMI, IP stream (RJ-45) |
| Audio inputs | Euroblock line 5-p Balanced Stereo Audio |
| Control | Ethernet/IP (RJ-45), Front buttons, IR cable connection, On-screen display, RS-232, Web interface |
| USB passthrough | Yes 1x USB-B (Host) for KM/KVM use |
| Communication | |
| Switch Data Rate | |
| Switch Data Rate | 1GbE |
| Req. Network Switch | 1Gb Ethernet (PoE) |
| Energy | |
| Power Supply | |
| Power Supply | PoE on LAN port or 24V DC External Power Supply |
| Dimensions and weight | |
| Width | |
| Width | 189 mm |
| Depth | 145 mm |
| Height | 27.6 mm |
| Net weight | 0.67 kg |
| Additional information | |
| Installation | |
| Installation | 19" Rack, 1U With optional rack adapter |
| Installation | Freestanding/Shelf |
| Included Accessories | 2 Bracket sets, Quick start guide |
| Warranty | 7 years |
| Packaging info | |
| Packaging size | |
| Packaging size | 320 x 180 x 80 mm |
| Packaging weight | 900 g |
| Marca | Otros |
|---|---|
| MPN: | 60-000590 |
