Belden CAD1100004 patchcord 28awg cat6a cmr negro 4ft

Precio especial $448.00 IVA incluido + Envio $150 MXN
Antes $520.00
Disponible 34 Pzas
sku: CAD1100004
pub
MX0000103160
Precios sujetos a cambios sin previo aviso
Pagos 100% seguros
Entrega Aprox.
Envio Nacional | Condicion: Nuevo
Logo

10GX UTP CMR 28AWG Patch Cords

Specifications

Product Overview

Suitable Applications

IBDN System 10GX, TIA Category 6A, ISO Class EA, 10GBASE-T

Physical Characteristics (Overall)

Total Number of Pairs

4

Overall Nominal Diameter

0.186 in

Wiring Scheme

T568A/B-T568A/B

Packaging

Individually packaged in a clear plastic bag.

Connectors
MATERIALS
Description Material Color
Boot Elastomer Translucent
Conductor BC - Bare Copper
Front Connection Blades Phosphor Bronze with 50u inch Gold over Nickel Plating
Inner Jacket PVC - Polyvinyl Chloride
Insulation PO - Polyolefin
Outer Jacket PVC - Polyvinyl Chloride
Electrical Characteristics

Dielectric Strength

1,000 V RMS @ 60 Hz for 1 minute

Current Rating

1.500 A

Insulation Resistance

500 M-Ohm Minimum

Max Contact Resistance

20 mOhm

Temperature Range

Installation Temperature Range

-10°C To +60°C

Storage Temperature Range

-40°C To +70°C

Operating Temperature Range

-10°C To +60°C

Mechanical Characteristics

Min Bend Radius (Overall Cable)

.744 in

Plug /Jack Compatibility

RJ45

TERMINATION INTERFACE
Connection Durabilities
Mated Connection 750 Cycles
Standards

UL Rating

Riser

Data Category

Category 6A

TIA/EIA Compliance

Category 6A - TIA 568-C.2, Class EA - ISO/IEC 11801:2002 Ed.2 Amendment 2

Other Standards

FCC Part 68, Subpart F, IEC 60603-7

Applicable Environmental and Other Programs

Environmental Space

Riser

EU Directive 2002/95/EC (RoHS)

Yes

MII Order #39 (China RoHS)

EUP 50

Flammability, LS0H, Toxicity Testing

Safety Listing

c(UL)us Listed

Related Part Numbers

Related Parts

10GX Modular Jacks and Couplers, 10GX Patch Panels

Product Notes

Labeling

Belden Part Number, Performance Acronym, Wiring Scheme and Cord Length.

History

Update and Revision

Revision Number: 0.5 Revision Date: 09-23-2024

Part Numbers
Item # Color Length
CAD1100003 Black 3 ft
CAD1100004 Black 4 ft
CAD1100005 Black 5 ft
CAD1100006 Black 6 ft
Más información
MarcaBelden
MPN:CAD1100004
