Bosch PRA-ES8P2S m_praes8p2s - switch ethernet / 8xpoe 2xsfp
Precio especial $72,652.00 IVA incluido + Envio $150 MXN
Antes $84,276.00
Disponible 0 Pzas
Antes $84,276.00
Disponible 0 Pzas
Agotado
pub
MX0000103145
Switch Ethernet, 8xPoE, 2xSFP
- 8 puertos Gigabit con PoE
- 2 puertos Gigabit combinados con tomas SFP para transceptores de fibra de vidrio
- Redundancia de red mediante STP/MSTP/RSTP
- Conexiones de fuente de alimentación duales
- Relé de fallo
Especificaciones clave
| Dimensiones (Alto x Ancho x Fondo) (mm) | 152 x 74 x 105 mm |
| Peso (kg) | 1.30 kg |
| Protección | Dispositivo de control; RSTP; Limitación de velocidad; Control de tormentas |
| Protocolos/estándares | HTTP; HTTPS; Telnet; SNMP (V1, MIBII); SNMP (V2c, MIBII); SNMP (V3, MIBII); SMTP; SNTP; SNMP |
| Temperatura de funcionamiento (°C) | -40 – 75 °C |
| Tensión de funcionamiento (VCC) | 16.80 – 62.40 VDC |
Features
- 2 x Gigabit combo ports with SFP sockets for glass fiber transceivers
- Network redundancy via STP/MSTP/RSTP
- Dual power supply connections
- Fault relay
- Supports optical fibre cable to span longer distances and provided high data transmission rates between servers and network components
- Up to 10x faster than standard Ethernet server connectivity while providing high-performance uplinks
- Layer 2 switch provides a complete lineup of features including IGMP snooping, port mirroring, and spanning tree
| Informacion tecnica | |
|---|---|
| General Information | |
| Brand Name | Bosch |
| Manufacturer | The Bosch Group |
| Manufacturer Part Number | F.01U.352.102 |
| Packaged Quantity | 1 |
| Product Line | PRAESENSA |
| Product Model | PRA-ES8P2S |
| Product Name | PRA-ES8P2S Ethernet Switch, 8xPoE, 2xSFP |
| Product Series | PRA |
| Product Type | Ethernet Switch |
| Technical Information | |
| Media Type Supported | Optical Fiber, Twisted Pair |
| Power Consumption | 140 W |
| I/O Expansions | |
| Expansion Slot Type | SFP (mini-GBIC) |
| Number of SFP Slots | 2 |
| Number of SFP+ Slots | 2 |
| Number of Total Expansion Slots | 2 |
| Shared SFP Slot | Yes |
| Interfaces/Ports | |
| Modular | Yes |
| Port/Expansion Slot Details | 2 x Gigabit Ethernet TP/SFP Combo, 8 x Gigabit Ethernet PoE |
| Total Number of Network Ports | 8 |
| Management & Protocols | |
| Manageable | Yes |
| Media & Performance | |
| Network Technology | 10/100/1000Base-T, 1000Base-X |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Layer Supported | 2 |
| Physical Characteristics | |
| Depth | 105 mm |
| Form Factor | DIN Rail Mount, Wall Mount |
| Height | 152 mm |
| Weight (Approximate) | 1.30 kg |
| Width | 74 mm |
| Power Description | |
| Input Voltage | 16.8V DC, 62.4V DC |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 120W |
| Power Source | PoE, Power Supply |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Package Contents |
|
| Marca | Bosch |
|---|---|
| MPN: | PRA-ES8P2S |
