Eaton GHB3050 type ghb breaker 3p 50a 277/480vac max 125/250vdc 14kaic
Precio especial $2,311.00 IVA incluido + Envio $150 MXN
Antes $2,681.00
Disponible 3 Pzas
Antes $2,681.00
Disponible 3 Pzas
sku: GHB3050
pub
MX0000102200
GHB3050
Eaton Series C complete molded case circuit breaker, G-frame, GHB, Complete breaker, Fixed thermal, Fixed magnetic trip type, Three-pole, 50 A, 480Y/277 Vac, 125/250 Vdc, 50/60 Hz
General specifications |
|
| Product Name | Eaton Series C complete molded case circuit breaker |
| Catalog Number | GHB3050 |
| UPC | 786679911297 |
| Product Length/Depth | 2.63 in |
| Product Height | 4 in |
| Product Width | 3 in |
| Product Weight | 1.75 lb |
| Compliances | Federal Specifications Classification W-C375B |
| Certifications | UL Listed |
Especificaciones del producto |
|
| Type | Molded case circuit breaker |
| Amperage Rating | 50 A |
| Voltage rating | 480Y/277 Vac, 125/250 Vdc |
| Trip Type | Fixed thermal, fixed magnetic |
| Circuit breaker type | GHB |
| Circuit breaker frame type | Complete breaker |
| Series | Series C |
| Frame | G |
| Frequency rating | 50/60 Hz |
| Interrupt rating | 14 kAIC at 480Y/277 Vac 65 kAIC at 240 Vac |
| Number of poles | Three-pole |
| Marca | Eaton |
|---|---|
| MPN: | GHB3050 |
