Belden FPS4F4F003M - fxpc os2 mpo8_f 3m ofnp rd_2.0 type-b yl_jkt
Precio especial $2,536.00 IVA incluido + Envio $150 MXN
Antes $2,942.00
Disponible 6 Pzas
Antes $2,942.00
Disponible 6 Pzas
sku: FPS4F4F003M
pub
MX0000101963
FPS4F4F003M
FX PATCH CORD, OS2, MPO-12 BASE 8 (F) - MPO-12 BASE 8 (F), 3 M, OFNP, ROUND 2.0 MM, TYPE-B, YELLOW JACKETbr
Product Overview
| Suitable Applications: | Data Center, LAN, Equipment Room, Telecommunication room, Workstation Area |
Fiber Specifications
| Fiber Type: | OS2 |
| Fiber Core Diameter: | 8.2/125 µm |
| Fiber Count: | 8 |
| Fiber Color Coding: | TIA-598-D |
Physical Specifications
Connectors
| Description | Type | Housing Material | Housing Color | Boot Material | Boot Color |
|---|---|---|---|---|---|
| Connector A (Inside End) | MPO-12 (Base 8) Female | Plastic | Green | Rubber | Black |
| Connector B (Outside End) | MPO-12 (Base 8) Female | Plastic | Green | Rubber | Black |
Assembly Cable
| Cable Nominal OD | Jacket Color |
|---|---|
| 2.0 mm | Yellow |
Measurement
| Overall Assembly Length | Packaging |
|---|---|
| 3 m (10 ft) | Individually packaged in a plastic bag |
Overall Length Tolerances
| Range | Tolerance |
|---|---|
| 0 to 2 meters | +0.2 / -0 meter |
| 2.1 to 4.9 meters | +0.3 / -0 meter |
| 5 to 40 meters | +0.4 / -0 meter |
| over 40 meters | +1.0% / -0% |
Armor Specifications
| Armor Type and Material: | No Armor |
Optical Characteristics
Polarity Identification:Type-B
Fiber Connector Performance
| Description | Connector Type | Max. Insertion Loss | Min. Return Loss |
|---|---|---|---|
| Connector A (Inside End) | MPO-12 (Base 8) Female | 0.35 dB | 60 dB |
| Connector B (Outside End) | MPO-12 (Base 8) Female | 0.35 dB | 60 dB |
Mechanical Characteristics
| Min. Bend Radius During Installation: | 15x Cable OD |
| Min. Bend Radius During Operation: | 10x Cable OD |
Temperature Range
| Operating Temperature Range: | -10C to +60C |
| Storage Temperature Range: | -10C to +60C |
Standards and Compliance
| Environmental Suitability: | Indoor |
| Flammability / Reaction to Fire: | OFNP |
| UL Rating: | Plenum |
| TIA/EIA Compliance: | TIA/EIA 568.3 |
| European Directive Compliance: | EU Directive 2011/65/EU (RoHS 2) |
| MII Order #39 (China RoHS): | EUP 50 |
| Other Standard Compliance(s): | ACMA |
Product Notes
| Related Parts: | DCX system, FX UHD Patch Panels, ECX Patch Panels, FX Patch cords, FX MPO Trunks, FX Multi-fiber Trunks |
History
| Marca | Belden |
|---|---|
| MPN: | FPS4F4F003M |
