Infocus SP2238ST screenplay multimedia projector data standard throw 4000 ansi lumens dlp 1080p (1920x1080) 3d white
Precio especial $17,027.00 IVA incluido + Envio $150 MXN
Antes $19,751.00
Disponible 0 Pzas
Antes $19,751.00
Disponible 0 Pzas
Agotado
pub
MX0000100267
SP2238ST
The ScreenPlay VISTA DLP projectors are our first projectors that meet the communication standards for the Crestron Connected Network Communication Protocols and are compatible with the Crestron XiO Cloud® Service. The complete VISTA lineup of six models of various resolutions and lens types are Crestron certified.
Here’s why we’re excited to release second-generation Crestron Connected® enabled devices. Crestron Connected now delivers even more robust control of third-party devices, including displays and projectors. It also includes the added benefit of compatibility with the XiO Cloud® platform to remotely monitor and manage those devices. Here’s what else you get:
A new, API-based protocol proven to offer faster responses between devices and the room control system, as well as more device feedback relative to specific statuses.
Backwards compatibility with first-gen Crestron Connected devices.
Support for TLS and authenticated connections for enhanced security.
Compatibility with RoomView® software and Crestron Fusion, Crestron Fusion Cloud, and XiO Cloud platforms.
Fully compatible with existing and new Crestron control systems, as well as our enterprise-grade, server-based control system, Virtual Control.
No longer requires Adobe Flash.
Programming interfaces expanded to include capability reports, so a programmer can query a device for what features are included vs. not included.
Optional device features are now advertised to the control system program to give clients more choices of what to control and monitor.
The VISTA lineup is also compatible with all other major network protocol standards including PJLink, AMX Dynamic discovery, Extron IPLink, and an extensive set of RS232 commands.
Designed for the enterprise customer, the VISTA lineup offers outstanding ultra-long lamp life, high brightness, and superb connectivity, which includes 2x HDMI ports.
- Vibrant colors.
- Outstanding readability and contrast.
- Compact and lightweight form.
- Versatile portable display solution.
- Short-throw models add further versatility and installation options to the line, making them suitable for fixed installations and 24/7 operation.
The complete VISTA line is also easy on the eye with its sleek matte white finish, understated branding, and matching accessories.
Here’s why we’re excited to release second-generation Crestron Connected® enabled devices. Crestron Connected now delivers even more robust control of third-party devices, including displays and projectors. It also includes the added benefit of compatibility with the XiO Cloud® platform to remotely monitor and manage those devices. Here’s what else you get:
A new, API-based protocol proven to offer faster responses between devices and the room control system, as well as more device feedback relative to specific statuses.
Backwards compatibility with first-gen Crestron Connected devices.
Support for TLS and authenticated connections for enhanced security.
Compatibility with RoomView® software and Crestron Fusion, Crestron Fusion Cloud, and XiO Cloud platforms.
Fully compatible with existing and new Crestron control systems, as well as our enterprise-grade, server-based control system, Virtual Control.
No longer requires Adobe Flash.
Programming interfaces expanded to include capability reports, so a programmer can query a device for what features are included vs. not included.
Optional device features are now advertised to the control system program to give clients more choices of what to control and monitor.
The VISTA lineup is also compatible with all other major network protocol standards including PJLink, AMX Dynamic discovery, Extron IPLink, and an extensive set of RS232 commands.
Designed for the enterprise customer, the VISTA lineup offers outstanding ultra-long lamp life, high brightness, and superb connectivity, which includes 2x HDMI ports.
- Vibrant colors.
- Outstanding readability and contrast.
- Compact and lightweight form.
- Versatile portable display solution.
- Short-throw models add further versatility and installation options to the line, making them suitable for fixed installations and 24/7 operation.
The complete VISTA line is also easy on the eye with its sleek matte white finish, understated branding, and matching accessories.
Technical Information
| Projector | |
|---|---|
| Number of colours | 1.073 billion colors |
| Projector native resolution | 1080p (1920x1080) |
| Native aspect ratio | 16:10 |
| Supported aspect ratios | 4:3, 16:10, 16:9 |
| Screen size compatibility | 28 - 300' |
| Projection distance | 15.7 - 132.7' (0.4 - 3.37 m) |
| Contrast ratio (typical) | 30000:1 |
| Vertical scan range | 56 - 85 Hz |
| Horizontal scan range | 31.469 - 97.551 kHz |
| Projector brightness (economic mode) | 3040 ANSI lumens |
| Vertical synchronization (min) | 54 kHz |
| Vertical synchronization (max) | 85 kHz |
| Uniformity | 80% |
| Matrix type | DMD |
| Keystone correction, vertical | ± 20° |
| Horizontal synchronization (min) | 15 kHz |
| Horizontal synchronization (max) | 97 kHz |
| Digital gamma correction | No |
| Projection technology | DLP |
| Projector brightness | 4000 ANSI lumens |
| Light source | |
| Light source type | Lamp |
| Service life of light source | 8000 h |
| Lamp type | UHP |
| Lamp power | 203 W |
| Service life of light source (economic mode) | 15000 h |
| Lens system | |
| Zoom ratio | 1.1:1 |
| Zoom capability | No |
| Focus | Manual |
| Throw ratio | 0.496:1 |
| Offset | 116% |
| Zoom type | Fixed |
| Interchangeable lens | No |
| Video | |
| Analog signal format system | NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM |
| Full HD | No |
| 3D | Yes |
| Supported video modes | 480i, 480p, 576i, 720p, 1080i, 1080p |
| Supported graphics resolutions | 800 x 600 (SVGA), 854 x 480 (WVGA), 1024 x 600, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA) |
| Adjustable colour temperature | Yes |
| Ports & interfaces | |
| Mobile High-Definition Link (MHL) | No |
| HDMI connector type | Full-size |
| HDBaseT port | No |
| PC in (D-Sub) | Yes |
| DC-in jack | No |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 2 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
| Microphone in | No |
| S-Video inputs quantity | 1 |
| Serial interface type | RS-232 |
| PC Audio out | Yes |
| PC Audio in | Yes |
| HDMI version | 1.4b |
| DVI port | No |
| AUX in | No |
| AC (power) in | Yes |
| S/PDIF out port | No |
| Common interface Plus (CI+) | No |
| Audio Return Channel (ARC) | No |
| Consumer Electronics Control (CEC) support | No |
| 3D sync port | No |
| Network | |
| Smart TV | No |
| Ethernet LAN | No |
| Wi-Fi | No |
| Bluetooth | No |
| Bluetooth Low Energy (BLE) | No |
| Miracast | No |
| Web browser | No |
| Features | |
| Interactive | No |
| Sync-on-green (SOG) | No |
| Separate H/V sync | Yes |
| Composite sync | No |
| Password protection | Yes |
| Electronic Programme Guide (EPG) | No |
| HDCP | Yes |
| Preset modes | Presentation, Bright, Cinema, sRGB, Blackboard, Custom, 3D |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Arabic, Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, French, Hindi, Hungarian, Indonesian, Italian, Norwegian, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| Noise reduction | No |
| Noise level | 30 dB |
| Noise level (economic mode) | 26 dB |
| Certification | UL and c-UL, FCC, CE, CCC+CECP, NOM, PCT/CU/EAC, CB, Nemco/GS |
| Air filter | No |
| Trumotion technology | No |
| HID support | No |
| Teletext function | No |
| Hybrid Broadcast Broadband TV (HbbTV) | No |
| Hotel mode | No |
| High Dynamic Range (HDR) supported | No |
| 4K Ultra HD upscaling | No |
| Eye protection | No |
| Projection modes | Ceiling, Front, Rear |
| Screen mirroring | No |
| Sleep timer | Yes |
| Number of OSD languages | 27 |
| Test patterns | No |
| Auto signal detection | Yes |
| Standby timer | No |
| Menu position select | No |
| Multimedia | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 1 |
| Video formats supported | 3GP, AVI, MOV, MP4, MPEG, MPG, RM, RMVB |
| Image formats supported | BMP, JPEG XR, JPG, PNG |
| Audio formats supported | AAC, MP3, WAV, WMA |
| TV tuner integrated | No |
| RMS rated power | 10 W |
| Logical Channel Number (LCN) | No |
| Equalizer | No |
| Built-in microphone | No |
| Design | |
| Market positioning | Business |
| Product type | Standard throw projector |
| Housing material | Plastic |
| Cable lock slot type | Kensington |
| Product colour | White |
| LED indicators | Yes |
| Cable lock slot | Yes |
| Placement | Desktop, Ceiling |
| Display | |
| Built-in display | No |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 267 W |
| Power source | AC |
| Power consumption (typical) | 267 W |
| Power consumption (standby) | 0.5 W |
| Auto power off | Yes |
| Power consumption (economy mode) | 210 W |
| Processor | |
| Built-in processor | No |
| Supplier features | |
| Battery type | AA |
| Recommended gender | Any gender |
| Assembly required | No |
| Batteries required | Yes |
| Invoice unit | Yes |
| Orderable unit | Yes |
| Manual languages (ISO 639 format) | Multi |
| Operational conditions | |
| Storage temperature (T-T) | -10 - 60 °C |
| Operating temperature (T-T) | 5 - 40 °C |
| Operating altitude | 0 - 120000' (0 - 3048 m) |
| Weight & dimensions | |
| Package width | 15.6' (395 mm) |
| Package depth | 13.3' (337 mm) |
| Package height | 6.54' (166 mm) |
| Weight | 5.73 lbs (2.6 kg) |
| Width | 12.3' (313 mm) |
| Depth | 9.29' (236 mm) |
| Height | 3.78' (96 mm) |
| Package weight | 9.04 lbs (4.1 kg) |
| Packaging content | |
| 3D glasses included | No |
| Tripod included | No |
| Remote control included | Yes |
| Battery type | AA |
| Remote control type | IR |
| Mounting brackets included | No |
| Manual | Yes |
| Carrying case | No |
| Cables included | AC, VGA |
| Batteries included | No |
| AC adapter included | No |
| Interactive pen included | No |
| Technical details | |
| Sustainability compliance | Yes |
| Marca | Infocus |
|---|---|
| MPN: | SP2238ST |
