Dell 87970465 almacenamiento powervault me5012 san 12xlff 2x16tb 8x10gb iscsi 3 años prosoporte
Precio especial $226,688.00 IVA incluido + Envio $150 MXN
Antes $262,958.00
Disponible 0 Pzas
Antes $262,958.00
Disponible 0 Pzas
Agotado
pub
MX0000097498
| Marca: | Dell |
| Artículo: | Almacenamiento |
| Serie: | PowerVault |
| Modelo: | ME5012 |
| Capacidad: | 2x16TB |
| Otros: | SAN 12xLFF 8x10Gb iSCSI |
| Soporte: | 3 Años ProSoporte |
*Datos de referencia, es necesario contactarnos para la ficha tecnica.
Technical Specifications:
| PowerVault ME4 Series | ME5012 |
|---|---|
| Chassis Overview | |
| Chassis format | All-in-one (single/dual controllers, internal drive bays, networking) with expansion options |
| Rack size | 2U |
| Controllers | 2 hot-swappable per chassis (dual active) Single/dual controller support for 2U |
| Processors | Intel Xeon Processor |
| Internal storage | 12 x 3.5” drive bays (2.5” drive carriers supported) |
| System memory | 16GBper controller (32GB total) |
| Expansion Capacity | |
| Min/Max drive count | 2/264 |
| Max raw capacity | 2.40PB (with 9xME412 expansion) 1.83PB (with 9xME424 expansion) 1.89PB (with 9xME424 expansion) 5.28PB (with 3xME484 expansion) |
| NAS Support | Supported with NX Series Windows NAS appliance |
| Storage media | SAS and NL-SAS drives; different drive types, transfer rates, rotational speeds can be mixed in the same system:
|
| Network and Expansion I/O | |
| Host interface | FC, iSCSI (optical or BaseT), SAS |
| Max 32Gb FC ports | 8 per array (support auto-negotiate to 16Gb) |
| Max 25Gb iSCSI ports | 8 SFP+ or SFP28 ports per array |
| Max 10Gb iSCSI ports | 8 BaseT ports per array (only support auto negotiate to 1Gb) |
| Max 12Gb SAS ports | 8 12Gb SAS ports |
| Max management ports | 2 per array (1Gb BASE-T) |
| Disk expansion protocol | 12Gb SAS |
| Disk interface expansion ports | 2 12Gb SAS (wide-Port) per array (1 port per controller) Up to 9 2U expansion enclosures per 2U base array Up to 3 5U expansion enclosures per 2U base array Up to 3 5U expansion enclosures per 5U base array |
| ME4012 | |
| Functional | |
| Array configurations | All-flash, hybrid flash, HDD only arrays |
| Storage format | Native block-level SAN or DAS |
| Data Optimization | |
| Auto-tiering | Up to 3 primary (media-based) tiers |
| RAID support | RAID 1, 5, 6, 10, or ADAPT RAID; any combination of RAID levels can exist in single array |
| Adapt | Distributed erasure coding that reduces rebuild times when drive failures occur |
| Thin provisioning | Active by default on all volumes, operates at full performance across all features |
| Snapshots | 1024 maximum snapshots per array |
| Data Mobility and Migration | |
| Replication | Asynchronous replication via FC or iSCSI – ME4 to ME5; ME5 to ME4; ME5 to ME5 Target/source relationships may be one-to-many or many-to-one |
| Volume copy | Copy complete standalone volumes |
| Data Protection, Disaster Recovery, Security | |
| Business continuity | VMware Site Recovery Manager |
| Data-at-rest encryption | Self-encrypting drives (SEDs) in SSD or HDD formats Full Disk Encryption (FCE) based on AES-256 Drives certified to FIPS 140-2 Level 2 |
| Key manager | Internal controller key management |
| Management | |
| Management | PowerVault Manager HTML5 GUI element manager, CLI, OpenManage Enterprise 3.9 |
| VMware vCenter | VMware vCenter plugin to manage ME5 arrays through vCenter. |
| Scripting | CLI API Redfish/Swordfish REST API |
| Host OS support | Windows 2022, 2019 and 2016 RHEL 8.2 and 7.8 SLES 15.2 and 12.5 VMware 7.0 and 6.7 Citrix XenServer 8.x and 7.x |
| Virtualization integration | VMware vSphere (ESXi) vCenter; SRM Microsoft Hyper-V |
| ME5012 | |
| Physical | |
| Rack size | 2U |
| Height | 8.79 cm (3.46 inches) |
| Width | 48.30 cm (19.01 inches) |
| Depth | 61.87mm (24.36 inches) |
| Weight at max configuration | 32.00 kg (71.00 lbs) |
| Weight empty | 4.80 kg (10.56 lbs) without drives |
| Power | |
| Power/wattage | 580W |
| Heat dissipation | 1980 BTU |
| Voltage | 100-240 VAC |
| Frequency | 50/60 Hz |
| Amperage | 7.6-3.0A (x2) |
| Environmental Operating Conditions | |
| Operating temperature | 5°C - 35°C (41°F - 95°F, derated by 1°C per 300mm above 900m) |
| Non-operating temperature | -40°C to 70°C (-40 to 158°F) Maximum temperature changes in an hour: 20°C |
| Operating humidity ranges (non-condensing) | -12C dew point minimum, 8% to 85% maximum, non-condensing |
| Non-operating humidity (noncondensing) | 21°C dew point maximum, 5% to 100% maximum, non-condensing |
| Services, Warranties | |
| Services | Dell ProSupport Enterprise Suite and DellProDeploy Enterprise Suite. Optional ProSupport Plus is available offering pro-active and preventative services to improve performance and stability. |
| System sizing | Dell Power Sizer |
| Marca | Dell |
|---|---|
| MPN: | 87970465 |
