Input

32Ch over Network

Output

HDMI1 (4K 30/60Hz, 1080P, 1280x1024), HDMI2 + VGA (1280x1024, 1080P)

Video

View Mode

Independent, Up to 32ch on monitor1 + 9ch on monitor2

*Under Advanced Face Recognition Mode: Up to 24ch on monitor1

Decoding Format

H.265 / H.265+ / H.265S / H.264

Decoding Capabilities

1Ch - 12MP ; 4Ch - 2MP ; 9-32Ch - D1

Input

1CH RCA (Linear, 1kΩ) + IPC inputs

Output

1CH RCA (2.0 Vp-p, 1 kΩ) + IPC inputs

Audio

Compression

G.711A/G.711U

Two Way Audio

Yes

Analytics Channels

32Ch (requires supporting IPC)

Analytics

Supported Analytics

Camera Tampering, Line Crossing (DDA / Pixel Based), Sterile Area (DDA / Pixel Based), Object Monitoring, Object Counting (DDA), Crowd Gathering, People Intrusion, Smart Search, Face Rec- ognition, LPR.

Advanced Face Recognition Mode: Supports up to 2 Non-AI IPC and performs face detection and recognition.

Face Recognition Rate

180 Faces per minute (All Channels) / 3 Faces per second (Single Channel)

Bandwidth

Incoming

160Mbps

Outgoing

160Mbps

Real-Time Recording

32CH 8MP real-time 12MP - 20FPS

Record / Remote App

Record/ Main Stream

Record Type

Video / Video + Audio

12MP

640FPS (NTSC)/640FPS (PAL)

8MP

960FPS (NTSC)/800FPS (PAL)

5MP and lower

960FPS (NTSC)/800FPS (PAL)

Master stream over network

Up to 32CH@Recording resolution

Record / Remote App

Sub Stream

Resolution

Depends on IPC

Sub-Streams over Network

Up to Outgoing Bandwidth Capacity

General

Recording Modes

Schedule, Manual, Motion, Sensor, Analytics, POS and all combinations

Remote Applications

User Access

128 Users online with Professional Autorithy Management

Mobile App

Provision Cam2 for iOS/Android

PC/Mac Software

Ossia VMS Standard / Enterprise

Plug-in free Web-Browser

Chrome, FireFox, Safari, Edge, Opera. (All Limited to 4Ch Live View/Playback)

Plug-in based Web-Browser

Internet Exporer

Playback

Local Playback

16Ch

Remote Playback (Web, App, VMS)

32Ch on IE, 4Ch on H5

Search Mode

DDA Object, Smart Search, LPR, Face Recognition, Time-Slice, Time, Event, POS

Backup

USB

2 USB 2.0 Port + 1 USB 3.0 Port

Backup Format

AVI (Unencrypted) / Private Format (Encrypted / Unencrypted)

Alarm

Input

16+IPC

Output

4+IPC

Storage

HDD

8

E-SATA

2

Max Capacity

80TB (Up to 10TB Each) External: Up to 10TB

RAID

Yes (0/1/5/6/10)

Connection

via Network

PTZ

Supported Controls

Pan, Tilt, Zoom, Preset, Cruise, Scan, Iris, Focus

RS-485

Yes (C06 Keyboard Connection)

Ethernet

2x1000/100/10Mbps self-adaptive Ethernet interface with Fault Tolerance / Dual Network Configu- ration

Network

Protocols

TCP/IPv4/IPv6, DHCP, DDNS, NTP, SMTP, SSL/TLS, UPnP, P2P, RTSP, FTP, HTTPS, 820.1X,

SNMP, Auto Report (Ossia VMS)

ONVIF

Full Device Support (Profile T/G, ONVIF Version 20.12)

Ports

N/A

Speed

N/A

PoE

Standard

N/A

CCTV Mode

N/A

Total Power

N/A

Max. Power Output (Per Ch.)

N/A

Power Supply

AC100/240V

Others

Power consumption (No HDD)

30W

Dimension

W445xD436xH90mm

Operation Temperature

0~50°C
