Informacion tecnica
Camera
Image Sensor 2.54cm (1/2.8inch) Progressive Scan CMOS
Min. Illumination 0.01Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Speed 1/3 s to 1/100,000 s
Lens 2.8 mm, horizontal field of view 105.8° [2.0 mm (126°), 4 mm (83°), optional]
Lens Mount M12
Day &Night IR cut filter with auto switch
Digital Noise Reduction 3D DNR
Wide Dynamic Range 120dB
Compression Standard
Video Compression H.264/MJPEG/H.264+
H.264 Type BaseLine Profile/Main Profile
Video Bit Rate 32 Kbps – 8 Mbps
Dual Streams Support
Audio Compression G.711/G.722.1/G.726/MP2L2
Audio Bit Rate 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-128Kbps(MP2L2)
Max. Resolution 2688 × 1520
Max. Frame Rate Main Stream 50Hz: 20fps (2688 × 1520), 25fps (1920 × 1080, 1280×720) 60Hz: 20fps (2688 × 1520), 30fps (1920 × 1080, 1280×720) Sub Stream 50Hz: 20fps (640 × 360, 352 × 288) 60Hz: 15fps (640 × 360, 352 × 240)
Image Settings Support rotate mode, brightness, saturation, sharpness, contrast are adjustable via web browser and client software
Day/Night Switch Support auto, scheduled, and triggered by alarm input
Others Mirror, Wide Dynamic Range (WDR), (Backlight Compensation)BLC, (Region of Interest) ROI
Network
Network Storage Support Micro SD/SDHC/SDXC card (up to 128 GB) local storage and NAS (NFS,SMB/CIFS), ANR
Detection Intrusion Detection, Line Crossing Detection, Motion Detection, Dynamic Analysis
Face Detection Detects the face appears in the surveillance scene and triggers linkage methods such as alarm info and email info
Alarm Trigger Tampering Alarm, HDD Full, HDD Error, Network Disconnected, IP Address Conflicted, Illegal Login
Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
Standard ONVIF (PROFILE S, PROFILE G), ISAPI
General Function One-key reset, Anti-flicker, Dual Streams, Heartbeat, Password Protection, Privacy Mask, Watermark, IP Address Filtering
Interface
Communication Interface 1 RJ45 10M/100M Ethernet port
On-board Storage Built-in Micro SD/SDHC/SDXC slot, up to 128GB
Audio 1build-in Mic, 1 build-in speaker
Alarm 1 alarm input, 1 alarm output
Reset Yes
Wi-Fi
Wireless Standards IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth 20/40MHz Support
Protocols 802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM
Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmit Output Power 11b: 17±1.5dBm @ 11Mbps 11g: 14±1.5dBm @ 54Mbps 11n: 12.5±1.5dBm
Reception Sensitivity 11b: -90dBm @ 11Mbps (Typical) 11g: -75dBm @ 54Mpbs (Typical) 11n: -74dBm (Typical)
Transfer Rates 11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps
Wireless Range 50 meters (The performance varies based on actual environment)
General
Operating Conditions -10 °C – 40°C (14 °F – 104 °F), Humidity 95% or less (non-condensing)
Power Supply 12 VDC ± 25%, PoE (802.3af)
Power Consumption Max. 5W
PIR Angle: 90°, Range: 8m
IR Range Approx. 10 meters
Dimensions 2.8mm, 4mm lens: 72.3 × 91.9 × 131.3mm (2.85inch × 3.62inch× 5.17inch) 2mm lens: 72.3 × 88.6 × 131.3mm (2.85inch × 3.49inch× 5.17inch)
Material Plastic
Weight 400g (0.88lbs)
