Commscope CO155D2-09F007 category 5e u/utp patch cord, rj45 to rj45, 4-pair, non-plenum, yellow jacket, 7 feet
Precio especial $271.00 IVA incluido + Envio $150 MXN
Antes $314.00
Disponible 0 Pzas
Antes $314.00
Disponible 0 Pzas
Agotado
pub
MX0000095649
CommScope Cat 5e U/UTP RJ45 Patch Cord, Non-Plenum
CO155D2
- Portfolio: CommScope®
- Product Series: CHD | CO
- Product Type: Twisted pair patch cord
- ANSI/TIA Category: 5e
- Interface, Connector A: RJ45 plug
- Interface, Connector B: RJ45 plug
- Jacket Color: Black | Blue | Green | Orange | Red | Slate | White | Yellow
- Interface Feature, connector A: Standard
- Interface Feature, connector B: Standard
- Cable Type: U/UTP (unshielded)
- Conductor Type: Stranded
- Environmental Space: Non-plenum
CO155D2
Product Classification
Regional Availability | Asia | Australia/New Zealand | Latin America | North America |
Portfolio | CommScope® |
Product Type | Twisted pair patch cord |
Product Series | CHD | CO |
Ordering Note | Cords < 1 m are valid elements for use in a channel or as an equipment interconnect but due to their limited length are not guaranteed to meet component compliance requirements that were developed to assess the quality of longer cords | Cords > 1 m are authorized for use in channels and are an effective standalone method used to connect active devices |
General Specifications
ANSI/TIA Category | 5e |
Cable Type | U/UTP (unshielded) |
Conductor Type | Stranded |
Interface, Connector A | RJ45 plug |
Interface Feature, connector A | Standard |
Interface, Connector B | RJ45 plug |
Interface Feature, connector B | Standard |
Jacket Color | Black | Blue | Green | Orange | Red | Slate | White | Yellow |
Pairs, quantity | 4 |
Transmission Standards | IEEE 802.3bt Type 4 |
Wiring | T568B |
Dimensions
Cable Assembly Length Range (m) | 1 – 30 |
Cable Assembly Length Range (ft) | 1 – 100 |
Cable Assembly Length Range (cm) | 15 – 999 |
Cable Assembly Length Range (in) | 6 – 999 |
Diameter Over Jacket | 5.36 mm | 0.211 in |
Compatible Conductor Gauge, stranded | 24 AWG |
Electrical Specifications
dc Resistance, maximum | 0.3 ohm |
Safety Voltage Rating | 300 V |
Material Specifications
Contact Plating Material | Gold in remating area | Nickel underplating |
Material Type | Phosphor Bronze | Polycarbonate |
Mechanical Specifications
Plug Insertion Life, minimum | 750 times |
Plug Retention Force, minimum | 133 N | 29.9 lbf |
Environmental Specifications
Operating Temperature | -10 °C to +60 °C (+14 °F to +140 °F) |
Environmental Space | Non-plenum |
Flammability Rating | CM |
Safety Standard | ETL | cETL |
Packaging and Weights
Packaging quantity | 1 |
Regulatory Compliance/Certifications
Agency | Classification |
ISO 9001:2015 | Designed, manufactured and/or distributed under this quality management system |
Marca | Otros |
---|---|
MPN: | CO155D2-09F007 |
