Arecont AV3196DN megavideo flex de 3mp wdr dia noche 2048x1536 21 fps mjpeg
Antes $11,104.00
Disponible 0 Pzas
WDR de 3MP, dia / noche verdadero, 21 fps, enfoque remoto, ranura SD, 2,8 mm discreto, 12 V CC / 24 V CA / PoE
La serie MegaVideo? Flex es una solución compacta de Camara IP todo en uno de sensor unico dia / noche real disponible en Resoluciones de 1.2MP, 1080p, 3MP o 5MP. Esta Camara esta? disenada para adaptarse a espacios compactos donde las limitaciones de las Camaras normales son un desafío. La simplicidad del diseno permite a los instaladores la flexibilidad de instalar la Camara en un ?rea y ocultar la unidad principal hasta 40 pies de distancia. ademas, ilumine la noche agregando hasta dos (2) iluminadores IR externos (se venden por separado).
Caracteristicas:
* Resolucion de 3MP
* Lente de 2,8 mm
* Enfoque remoto
* Verdadero dia / noche
* Amplio rango din?mico
* Ranura para tarjetas SD
* Bajo techo, en exteriores
* Accesorio IR opcional
* alimentacion a través de Ethernet
*Producto con Empaque y/o componentes variables. *Este producto no aplica para Devolucion y/o Garantia una vez aceptada la entrega de mercancia/o paqueteria.
AV3196DN
The MegaVideo Flex camera transmits H.264 video to avoid straining your network. Power can be supplied via a single network cable or a 12 to 48 VDC/24 VAC power supply. The camera s interface is designed for intuitive, fast, and easy configuration. The AV IP Utility tool allows users to configure multiple cameras at one time when required.
Arecont Vision AV3196
| Image Sensor |
3 MP
|
| Optical Format |
1/3.2' CMOS
|
| Pixel Pitch |
2.2 μm
|
| Minimum Illumination |
Color Day Mode: 0.2 lux
Color Binning (Day Mode): 0.1 lux B&W Night Mode: 0.02 lux, IR sensitive |
| Resolution (H x V) |
Full Field of View:
2048 x 1536 1/4 Resolution: 1024 x 768 Scaled Resolution: 720p (1280 x 720) XVGA (1024 x 768) DVGA, 16:9 (1136 x 640) DVGA, 3:2 (960 x 640) SVGA (800 x 600) D1, PAL (720 x 576) 4CIF, PAL (704 x 576) D1, NTSC (720 x 480) 4CIF, NTSC (704 x 480) VGA (640 x 480) 2CIF, PAL (704 x 288) HVGA, 4:3 (480 x 360) 2CIF, NTSC (704 x 240) HVGA, 8:3 (640 x 240) HVGA, 3:2 (480 x 320) HVGA, 16:9 (480 x 272) CIF, PAL (352 x 288) CIF, NTSC (352 x 240) QVGA, SIF (320 x 240) QCIF, PAL (176 x 144) QCIF, NTSC (176 x 120) SQCIF (128 x 96) |
| Dynamic Range |
Up to 100 dB
|
| Frame Rates |
At Maximum Resolution: 21 fps (2048 x 1536)
Cropped: 21 fps (1920 x 1080, 1280 x 1024) Binning Mode: 21 fps (1024 x 768, 800 x 600, 960 x 540, 640 x 512) |
| Type |
2.8mm fixed lens, 1/2.5', f/1.8, IR corrected
|
| Horizontal Field-of-View |
89°
|
| Pixel Density |
30 ppf (100 ppm): 34.0 / 10.4 m
60 ppf (200 ppm): 15.5 / 4.7 m 90 ppf (300 ppm): 8.0 / 2.4 m |
| Optics |
M12 lens and remote focus module
|
| Low Light Capability |
Pixel binning mode
|
| Picture-in-Picture |
Simultaneous delivery of full field of view and zoomed images
|
| Shutter Speed |
Programmable: Controls motion blur, 1 to 500 ms
|
| Motion Detection |
Real-time, 1024 detection zones
|
| Privacy Masking |
Unlimited
|
| Cropping |
Flexible: Resolution windowing down to 1 x 1 pixel for JPEG and 2 x 2 pixels for H.264
|
| Backlight Compensation |
Custom white balance
|
| Flicker Filter Control |
5 to 255 Hz adjustable
|
| Image Rotation |
CorridorView (90°, 180°, and 270° image rotation)
|
| Wide Dynamic Range |
Auto switch control adjustment between WDR and LDR modes
|
| Noise Reduction |
Low-light noise filter control
|
| Efficiency |
SNAPstream (Smart Noise Adaptation and Processing)
Bit rate and bandwidth limitation control Bandwidth and storage savings by running at 1/4 resolution |
| Sharpness |
Selectable enhancement level
|
| Onboard Storage |
microSD/SDHC card slot for up to 32 GB storage (card sold separately)
|
| Miscellaneous |
Programmable resolution, brightness, saturation, gamma, tint
Electronic pan, tilt, zoom (ePTZ) |
| Compression Type |
H.264 (MPEG-4, Part 10) / MJPEG
21 levels of quality |
| Network Protocols |
RTSP, RTP/TCP, RTP/UDP, HTTP, DHCP, TFTP, QoS, IPv4, IPv6, 802.1x
|
| Network Interface |
100Base-T Ethernet
|
| Multi-Streaming |
8 non-identical streams
|
| Industry Standards |
ONVIF Profile S conformant
|
| Listings |
UL CB Scheme: IEC 60950-1(Ed.2), IEC 60950-1(Ed.2); Am.1, IEC 60950-1(Ed.2); Am.2, IEC 60950-22(Ed.1))
|
| FCC Compliance |
Title 47, Part 15 (47 CFR 15) Subpart B Class A
|
| Environmental |
REACH 1907/2006/EC, WEEE 2012/19/EU
|
| CE Compliance |
2014/30/EU (EMC Directive), 2014/35/EU (Low Voltage Directive), 2011/65/EU (RoHS Directive) EN 55022:2010 Class A, EN 55024:2010, EN 61000-3-2:2006+A1:2009+A2:2009, EN61000-3-3: 2008 EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
|
| Mechanical |
Shock and vibration (EN61373), IK10
|
| Operating Temperature |
-4°F to 122°F / -20 to 50°C
|
| Humidity |
0 to 90% (non-condensing)
|
| Storage Temperature |
-4 to 140°F / -20 to 60°C
|
| Alarm Input / Output |
General purpose opto-coupled
1 x Input 1 x Output |
| Power Over Ethernet (PoE) |
PoE 802.3af, Class 3
|
| Power Consumption |
10.5 W DC Power max
14.2 W DC Power max (with two IR units on) |
| Auxiliary Power Input |
12 to 48 VDC / 24 VAC (Barrel plug, 2.1 mm I.D. x 5.5 mm O.D. x 9.5 mm)
|
| Casing |
Tamper-resistant housing, IK10 impact-resistant
Weather-resistant from front |
| USB Cable Length |
5 / 1.5 m
40 / 12 m |
| Dimensions |
Main Unit: 0.9 x 3.2 x 4.1' / 2.4 x 8.2 x 10 cm
Sensor Unit: Ø1.8 x 1.7' / Ø4.5 x 4.4 cm |
| Weight |
0.7 lb / 0.3 kg
|
| Package Weight |
2.85 lb
|
| Box Dimensions (LxWxH) |
6.2 x 6.2 x 6'
|
| Marca | Otros |
|---|---|
| MPN: | AV3196DN |
