Hoffman PTHW242430G2 protek dh wd gray type12

Precio especial $40,938.00 IVA incluido + Envio $150 MXN
Antes $47,488.00
Disponible 0 Pzas
Agotado
pub
MX0000090834
Precios sujetos a cambios sin previo aviso
Pagos 100% seguros
Entrega Aprox.
Envio Nacional | Condicion: Nuevo

ProTek Double-Hinge Window Type 4 12, 24.09x23.62x29.92, Lt Gray, Steel

  • Front and rear access to 19-inch rack equipment provided by three-part design: door, center section and wall section
  • Solid door provides complete physical and visual protection
  • Window door, made of scratch-resistant safety glass, provides visual monitoring of internal equipment while maintaining equipment protection
  • All seams are fully welded and ground smooth
  • Doors, center section and wall section are provided with ground studs to facilitate proper bonding and grounding of the cabinet
  • Premium seamless, foam-in-place gasket prevents contaminants from entering the cabinet
  • Key-locking wing knob is included on painted steel cabinet, providing access control to the cabinet; two keys are included with each cabinet
  • Stainless steel cabinet is provided with a quarter-turn slotted latch
  • One set of plated, self-grounding, tapped 10-32 rack angles per EIA universal spacing standards, which can be adjusted front-to-back, is provided with each center section of the cabinet; additional tapped- or square-hole rack angles can be added to the cabinet to provide additional mounting
  • On 28-inch (700 mm) wide enclosures, a 4-inch vertical cable manager with composite fingers is provided on hinge side of cabinet
  • Wall section welded panel studs which accommodate standard panels (steel and wood available), can be ordered separately

PRODUCT ATTRIBUTES

  • Height: 24.09 in / 612 mm
  • Width: 23.62 in / 600 mm
  • Depth: 29.92 in / 760 mm
  • Protection Rating: NEMA Type 12; NEMA Type 4; NEMA Type 4X; IP55; IK10
  • Material: Mild Steel
  • Finish: Powder Coated
  • Color: Light Gray
  • Color Code: RAL 7035
  • Body Thickness: 14 ga / 1.9 mm
  • Door Thickness: 16 ga / 1.52 mm
  • Rack Units: 12
  • Optional Wood Panel: CP2020W
  • Optional Steel Panel: CP2020
  • Additional Rack Angles: PTRA24T or PTRA24S
  • Weight: 100 lb
Más información
MarcaHoffman
MPN:PTHW242430G2
