Hanwha Techwin Wisenet QNO-6082R cámara bala híbrida / ahd 2 megapixel (1080p), 600tvl (cvbs)/ lente varifocal 3.2 - 10 mm ir 30 m ip66 ik10
Precio especial $10,167.00 IVA incluido + Envio $150 MXN
Antes $11,794.00
Disponible 1 Pzas
Antes $11,794.00
Disponible 1 Pzas
sku: QNO-6082R
pub
MX0000087489
H.265 + WiseStream
Mediante WiseStream, la tecnología de compresión de vídeo de Hanwha Techwin, la serie Wisenet X reduce el almacenamiento de datos hasta un 75% en comparación con la actual tecnología H.264, cuando se combina con la compresión H.265. Los costes del sistema se reducen enormemente sin comprometer la calidad de las imágenes.
Lente Varifocal para mejor visualización a mayor distancia.
La serie Q de Wisenet, le ofrece lentes varifocales de 3.2 - 10 mmpara tener un mayor alcance de visualización cuando se requiere distinguir objetos a distancia.
El alcance del lente se puede apreciar en el video.
Detección de Movimiento
Detección de Sabotaje
Detección de Desenfoque
Detección de Dirección
Linea Virtual
Entrada / Salida
Características principales:
- Sensor de imagen: 1/2.8 CMOS Scan Progresivo.
- Iluminación mínima: Color: 0.095Lux, B/N: 0Lux con IR encendido.
- Día / Noche real con filtro ICR.
- Lente motorizado: 3.2 - 10 mm.
- Distancia de IR: 30 m IR inteligente.
- Funciones: WDR real (120dB).
Compresión de vídeo y resolución máxima:
- Resolución máxima: 2 Megapíxel (1920 x 1080) a 30FPS.
- Compresión: H.265, H.264, MJPEG.
Funciones de red y almacenamiento:
- Almacenamiento: Soporta microSD de hasta 128GB (no incluida).
- ONVIF: Profile S/G, SUNAPI (HTTP API).
Características físicas y eléctricas:
- Temperatura de operación: -10 a 55 °C, humedad menor a 90%.
- Alimentación: 12 Vcc / PoE (802.3af) / 7.4W.
- Tipo de uso: Exterior / IP66 / IK10
- Dimensiones: Ø78 x 259.8 mm.
- Peso: 900 g.
3 años de garantía.
En Ingles FT:
Max. 2megapixel (1920 x 1080) resolution 0.095Lux (Color), 0Lux (B/W, IR LED on) 3.2 ~ 10mm (3.1x) motorized varifocal lens Max. 30fps@2M all resolutions (H.265/H.264) H.265, H.264, MJPEG codec supported, Multiple streaming Motion detection, Tampering, Defocus detection Hallway view (90 /270 ), LDC support Micro SD/SDHC/SDXC memory slot (Max. 128GB) IR viewable length 30m IP66, IK10, PoE/12VDC
Specifications
| Performance | |
|---|---|
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Design | |
| Form factor | Bullet |
| Product colour | Gray |
| Mounting type | Ceiling/wall |
| IK code | IK10 |
| International Protection (IP) code | IP66 |
| Housing material | Aluminum |
| Camera | |
| Minimum illumination | 0.095 lx |
| Adjustment shutter speed | Auto |
| White balance | ATW, AWC, Indoor, Manual, Outdoor |
| Camera shutter type | Electronic |
| Camera shutter speed | 5 s |
| Lens viewing angle, horizontal | 109° |
| Lens viewing angle, vertical | 57.4° |
| Lens viewing angle, diagonal | 132° |
| Image sensor | |
| Number of effective pixels (H x V) | 1920 x 1080 pixels |
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 1/2.8' |
| Lens system | |
| Maximum aperture number | 1.6 |
| Fixed focus | Yes |
| Focal length range | 3.2 - 10 mm |
| Night vision | |
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
| Video | |
| Noise reduction | Yes |
| Privacy masking | No |
| Flip & mirror | Yes |
| Maximum resolution | 1920 x 1080 pixels |
| Gain control type | Auto |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Back Light Compensation (BLC) | Yes |
| Supported graphics resolutions | 640 x 360, 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Video compression formats | H.264, H.265, M-JPEG |
| Frame rate | 30 fps |
| Total megapixels | 2 MP |
| Audio | |
| Signal-to-Noise Ratio (SNR) | 120 dB |
| Sample rate | 8 kHz |
| Audio formats supported | G.711, G.726 |
| Network | |
| Bluetooth | No |
| Ethernet interface type | 10 Gigabit Ethernet, 100 Gigabit Ethernet |
| Networking standards | IEEE 802.1x |
| Quality of Service (QoS) support | Yes |
| Number of users | 6 user(s) |
| Ethernet LAN | Yes |
| Streaming method | Multicast, Unicast |
| Wi-Fi | No |
| Supported network protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP |
| Storage | |
| Card reader integrated | Yes |
| Compatible memory cards | SD, SDHC, SDXC |
| Built-in HDD | No |
| Maximum memory card size | 128 GB |
| Flash memory | 256 MB |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security | |
| Alert notification type | |
| Video motion detection | Yes |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Management features | |
| Web browser | Yes |
| Power | |
| Power source type | PoE |
| Power consumption (typical) | 5.4 W |
| Power consumption (max) | 7 W |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 55 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 90% |
| System requirements | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Weight & dimensions | |
| Diameter | 3.07' (7.8 cm) |
| Length | 10.2' (259.8 mm) |
| Weight | 31.7 oz (900 g) |
| Packaging content | |
| Number of cameras | 1 |
| Marca | Otros |
|---|---|
| MPN: | QNO-6082R |
