Axis 0872-001 q3505-v mk ii fixed dome ip camera hdtv 1080p @ 60 fps 720p 120 3-9 mm p-iris vari-focal lens poe daynight ik10 and ip52 indoor casing zipstream mounting bracket 3-year warranty
Precio especial $21,302.00 IVA incluido + Envio $150 MXN
Antes $24,710.00
Disponible 0 Pzas
Antes $24,710.00
Disponible 0 Pzas
Agotado
pub
MX0000084180
Excellent image quality. Low bandwidth. AXIS Q3505-V Mk II provides images that are optimized for forensic purposes regardless of lighting conditions. It has enhanced Lightfinder technology for high-quality images even when they’re recorded in darkness. WDR – Forensic Capture ensures excellent detail when there are both bright and darker areas in a scene. And Axis’ Zipstream technology significantly reduces bandwidth and storage requirements, while preserving high-quality images. In addition, AXIS Q3505-V Mk II offers a wide range of viewing angles with standard (3-9 mm) and telephoto (9-22 mm) lens options available. Fast. Faster. Fastest. With up to 100/120 fps in HDTV 720p with WDR disabled and up to 30 fps in HDTV 1080p with WDR enabled, AXIS Q3505-V Mk II captures sharp images of fast-moving objects and people. So you’ll be able to identify people, objects and vehicles under difficult lighting conditions. The Electronic image stabilization greatly improves video quality in situations where the camera is subject to vibrations, providing smooth and comfortable live viewing. Installation that’s as easy as 1, 2, 3 The compact fixed-dome design of AXIS Q3505-V Mk II makes installation easy and cost-effective. And there are useful aids like level assistant, digital leveling and auto rotation available. AXIS Q3505-V Mk II also features versatile cable management with space for a service loop and optional connection to any kind of conduit. There’s a bracket included for mounting on junction boxes or directly on walls or ceilings, and there are optional accessories for recessed mounting or mounting on pendants. In addition remote zoom and focus capabilities provide convenient zooming and focusing over the network, eliminating the need for hands-on fine-tuning.
Specifications
| Performance | |
|---|---|
| Preset points | Yes |
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 11 |
| Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Portuguese, Russian |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Indoor |
| Auto-tracking | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Design | |
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling |
| International Protection (IP) code | IP52 |
| Housing material | Aluminum |
| Camera | |
| Minimum illumination | 0.02 lx |
| Viewing angle, horizontal | 105° |
| Viewing angle, vertical | 57° |
| Tilt angle range | -5 - 90° |
| Pan range | 0 - 360° |
| Angle of rotation | 190° |
| Camera shutter speed | 2 - 1/143000 s |
| Progressive scan | Yes |
| Image sensor | |
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 1/2.8' |
| Lens system | |
| Maximum aperture number | 1.3 |
| Zoom capability | Yes |
| Optical zoom | 3x |
| Digital zoom | 2x |
| Focal length range | 3 - 9 mm |
| Video | |
| Full HD | Yes |
| Image quality adjustment | Brightness, Contrast, Sharpness |
| Text caption overlay | Yes |
| Privacy masking | Yes |
| Image stabilizer | Yes |
| Video compression formats | H.264,M-JPEG |
| Maximum resolution | 1920 x 1080 pixels |
| Supported graphics resolutions | 240 x 135,256 x 144,320 x 180,448 x 252,480 x 270,512 x 288,640 x 360,960 x 540,1024 x 576 (WSVGA),1280 x 720 (HD 720),1366 x 768,1600 x 900,1920 x 1080 (HD 1080) |
| Supported video modes | 360p,576p,720p,1080p |
| Frame rate | 120 fps |
| Audio | |
| Sample rate | 8 kHz |
| Audio system | 2-way |
| Audio formats supported | AAC,ADPCM,G.711,G.726,OPUS,PCM |
| Network | |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.3af,IEEE 802.3at |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN | Yes |
| Cabling technology | 10/100Base-T(X) |
| Supported network protocols | IPv4/v6, HTTP , HTTPS, SSL/TLS a , QoS Layer 3 DiffServ , FTP , CIFS/SMB, SMTP , Bonjour , UPnP T M , SNMP v1/v2c/v3 (MIB - II), DNS, DynDNS, NTP , RTSP , RTP , SFTP , T CP , UDP , IGMP , RT CP , ICMP , DHCP , ARP , SOCKS, SSH |
| Storage | |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Internal memory | 512 MB |
| Flash memory | 256 MB |
| Ports & interfaces | |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Interface | RJ-45 |
| Connectivity technology | Wired |
| Memory | |
| Internal memory | 512 MB |
| Flash memory | 256 MB |
| Technical details | |
| Video compression formats | H.264,M-JPEG |
| Type | IP security camera |
| Form factor | Dome |
| PTZ control | Yes |
| Placement supported | Indoor |
| Product colour | White |
| Mounting type | Ceiling |
| Auto-tracking | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Progressive scan | Yes |
| Interface | RJ-45 |
| Security | |
| Alert notification type | |
| Video motion detection | Yes |
| Security algorithms | HTTPS,SNMP,SSH |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Active tampering alarm | Yes |
| Material | |
| Housing material | Aluminum |
| Power | |
| Power source type | PoE |
| Power consumption (max) | 6 W |
| Power over Ethernet (PoE) | Yes |
| Power consumption (typical) | 4.8 W |
| DC output voltage | 12 |
| Certificates | |
| International Protection (IP) code | IP52 |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 50 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Weight & dimensions | |
| Height | 4.58' (116.4 mm) |
| Diameter | 6.38' (16.2 cm) |
| Weight | 2.65 lbs (1.2 kg) |
| Packaging content | |
| Number of cameras | 1 |
| Quick installation guide | Yes |
| Mounting brackets included | Yes |
| Other features | |
| Video compression formats | H.264,M-JPEG |
| Marca | Axis |
|---|---|
| MPN: | 0872-001 |
