Cyberpower PR5000LCDRTXL5U ups de 5000 va 4500 w, topología línea interactiva, 200 - 240 vca entrada, 208 salida, onda senoidal pura, torre o rack 5 ur, con 3 tomas nema l6-30r y 2 l6-20r
Precio especial $61,838.00 IVA incluido + Envio $150 MXN
Antes $71,732.00
Disponible 0 Pzas
Antes $71,732.00
Disponible 0 Pzas
Agotado
pub
MX0000079824
*Nota: Este equipo debe ser arrancado por un experto de CyberPower para hacer efectiva la garantía. Para más información comunicarse con el departamento de Ingeniería.
Nota 2: Este equipo entrega voltaje a la salida de 200-240 Vca y NO deriva a 120 Vca por fase. Sí se requiere voltaje de salida a 120 Vca se requiere forzosamente el modelo PR5000LCDRTXL5UTF con transformador de bajada a la salida.
Para llevar a cabo el arranque del equipo deberá estar listo en la fecha programada con las siguientes características:
- Receptaculo toma-corriente de conexión NEMA L6-30R para clavija NEMA L6-30P.
- Nivel de voltaje de alimentación de 200 - 240 VAC.
- Calibre 8 AWG del cableado del UPS.
- Interruptor de entrada de 50 Ampers.
- Sistema de aterrizaje aislado bien referenciado a tierra.
Aplicaciones:
La fuente de poder ininterrumpible (UPS) Smart App PR5000LCDRTXL5U de Onda Senoidal Pura resguarda servidores de misión crítica, equipo de telecomunicaciones, VolP y sistemas de redes. Su regulador automático de voltaje entrega energía CA limpia y constante, protegiendo al equipo conectado y previniendo interrupciones costosas de negocio. Su patentada tecnología GreenPower UPS de circuito avanzada reduce los costos de ener- gía UPS en más del 75% comparada con los de los modelos competidores.
Especificaciones Técnicas:
- Voltaje de entrada: 200 - 240 Vca
- Tipo de conector de entrada: NEMA L6-30P
- Longitud del cable: 3 m.
- Frecuencia de entrada: 40 - 70 Hz.
- Salida VA: 5,000
- Salida Watts: 4,500
- Factor de Potencia: 0.9
- Voltaje en Batería: 200, 208, 220, 230, 240 Vac (Configurable) ±2%. No entrega salida de 120 Vca
- Transforamdores reductores de 220 a 120 Vac disponibles: OL8K10KRT3UTF
- Total de tomas de salida: 5
- Tipo de tomas: NEMA L6-30R (3)
y NEMA L6-20R (2)
- Administración Remota SNMP / HTTP: RMCARD205 (Opcional).
- Tiempo de respaldo con media carga: 26 minutos
- Tiempo de respaldo con carga completa: 10 minutos
- Módulo de Baterías Extendidas: BPL48V75ART2U
- Tiempo de transferencia: 4 ms.
- Indicadores: Pantalla LCD de lectura.
- Tamaño en Rack: 5 UR
- Dimensiones: 431.8 x 221.9 x 615.95 mm (Ancho x Alto x Profundidad)
- Peso: 100.69 kg
- 3 años de garantía (incluye batería).
Description
The CyberPower Smart App Sinewave PR5000LCDRTXL5U uninterruptible power supply (UPS) safeguards mission-critical servers, telecom equipment, VoIP and internetworking hardware that require seamless Pure Sinewave power. Its full automatic voltage regulation (AVR) boost/buck topology delivers a consistent and clean AC power, protecting connected equipment and preventing costly business interruptions. Patented GreenPower UPS™ advanced circuitry reduces UPS energy costs by up to 75% compared to competitive models. The PR5000LCDRTXL5U unit has a capacity of 5000VA/4000Watts, five (5) battery and surge-protected receptacles, including three (3) NEMA L6-30R twist lock receptacles and two (2) fail-safe NEMA L6-20R twist lock receptacles for critical loads. This UPS has sixteen (16) maintenance-free, user-replaceable 12V/9Ah batteries. The rotatable front LCD panel displays all major UPS vitals for ease of use. This unit offers connectivity via one (1) HID USB, two (2) DB9 serial and one (1) emergency power off (EPO) port. Protection for phone/network (RJ11/RJ45) is included. EMI/RFI filters increase the immunity of the load to noise disturbances. This UPS unit incorporates microprocessor-based fully digital control and includes PowerPanel® Business Edition software for unsurpassed flexibility and control. The addition of an optional SNMP/Network card allows for remote management via web browser or network management system (NMS). A Three-Year Warranty ensures that this UPS has passed our highest quality standards in design, assembly, material or workmanship and further protection is offered by a $300,000 Connected Equipment Guarantee. This CyberPower extended runtime (XL) model allows for the addition of up to ten (10) external battery packs. The battery packs are easy to plug-in and can be 'hot-swapped' to maintain system uptime during normal UPS maintenance. The BPL48V75ART2U battery pack is designed for this PR5000LCDRTXL5U model.
Specifications
| Power | |
|---|---|
| Output power | 4000 W |
| Surge energy rating | 2430 J |
| Emergency Power Off (EPO) | Yes |
| Output power capacity | 5 kVA |
| Performance | |
| UPS topology | Line-Interactive |
| LED indicators | Yes |
| Audible alarm(s) | Yes |
| Features | |
| UPS topology | Line-Interactive |
| Output power | 4000 W |
| Surge energy rating | 2430 J |
| Emergency Power Off (EPO) | Yes |
| Audible alarm(s) | Yes |
| Output power capacity | 5 kVA |
| Ports & interfaces | |
| USB 2.0 ports quantity | 1 |
| Serial ports quantity | 2 |
| Modem (RJ-11) ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 8 h |
| Hot-swap battery | Yes |
| Design | |
| Rack capacity | 5U |
| LED indicators | Yes |
| Product colour | Black |
| Display | LCD |
| Certification | FCC, UL 1778, CSA C22.2 No. 107.3-05, ROHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -15 - 45 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Weight & dimensions | |
| Weight | 222 lbs (100.7 kg) |
| Certificates | |
| Certification | FCC, UL 1778, CSA C22.2 No. 107.3-05, ROHS |
| Other features | |
| Dimensions (WxDxH) | 17 x 24.5 x 8.75' (431.8 x 622.3 x 222.2 mm) |
| Operating temperature (T-T) | 32 - 104 °F |
| Management platform | Self Test, Auto-Charge, Auto-Restart |
| Compatible operating systems | Windows 2000, 2003, XP, Vista, 7 |
| Marca | Cyberpower |
|---|---|
| MPN: | PR5000LCDRTXL5U |
