Planet gsd-804 Switch 8 Giga No-adm Datos
Precio especial $835.00 IVA incluido + Envio $150 MXN
Antes $969.00
Disponible 14 Pzas
Antes $969.00
Disponible 14 Pzas
sku: GSD-804
pub
MX00000052428
Optimal Solution for Energy Saving and Gigabit High Performance PLANET GSD-804 Green Networking Switch is an ideal solution in line with the energy-saving trend worldwide. The GSD-804 is an 8-port Gigabit Ethernet Switch, bringing both benefits of energy saving and Gigabit wire speed performance. It is specially designed for home networking, SOHOs and enterprises. Energy Saving The GSD-804, incorporating two advanced Green Networking technologies, is able to provide power saving by up to 40% but maintains high performance efficiently. (1) Hibernation Link Down power saving The Hibernation Link Down power saving goes beyond IEEE specifications to automatically lower power for a given port when it is not linked. With the Hibernation Link Down power saving technology, the GSD-804 will automatically adjust power usage of the ports that are shut down or not connected to network device. (2) Intelligent scales power based on cable length Intelligent scales power, the other technology adopted, is an intelligent algorithm that actively determines the appropriate power level based on cable length. When the GSD-804 is connected with Ethernet cable shorter than 20m, a device can obtain maximum power saving because the GSD-804 would automatically detect the Ethernet cable length and diminish power usage. The connected device can substantially reduce the overall power consumption, which makes a significant contribution to energy saving. Leading Home, SOHO and Workgroup Users to High-speed Networking Generation The GSD-804 is designed with modern plastic compact housing and easy to deploy high speed Gigabit networking in home or SOHO applications. Providing 16Gbps internal switching fabric, the GSD-804 can handle an extremely large amount of data in a secure topology linking to a backbone or high capacity servers. The GSD-804 provides 4K MAC address table and wire-speed packet transfer performance without risk of packet loss. The high data throughput of the device makes it ideal for most Gigabit environments, especially for the network to be upgraded to a Gigabit environment. Plug & Play All RJ-45 copper interfaces of the GSD-804 support 10/100/1000Mbps auto-negotiation for optimal speed detection through RJ-45 Category 5, 5e or 6 cables. They support standard auto-MDI/MDI-X feature which can detect the type of connection to any Ethernet device without requiring special straight or crossover cables.
| Ports & interfaces | |
|---|---|
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Performance | |
| Stackable | No |
| Auto-negotiation | Yes |
| Plug and Play | Yes |
| Harmonized System (HS) code | 85176990 |
| Technical details | |
| Product colour | Grey, White |
| Stackable | No |
| Housing material | Plastic |
| Rack mounting | No |
| Network | |
| Cable types supported | Cat5, Cat5e, Cat6 |
| MAC address auto-learning supported | Yes |
| MAC address auto-aging supported | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Full duplex | Yes |
| Flow control support | Yes |
| Auto MDI/MDI-X | Yes |
| 10G support | No |
| Auto-negotiation | Yes |
| Half duplex | Yes |
| Data transmission | |
| Jumbo frames | 9000 |
| Throughput | 11.9 Mpps |
| MAC address table | 4000 entries |
| Switching capacity | 16 Gbit/s |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Certificates | |
| Certification | FCC , CE |
| Design | |
| Wall mountable | Yes |
| Product colour | Grey, White |
| Stackable | No |
| LED indicators | Yes |
| Housing material | Plastic |
| Certification | FCC , CE |
| Rack mounting | No |
| Indication | |
| LED indicators | Yes |
| Power | |
| Output voltage | 5 V |
| Output current | 1 A |
| Power supply included | No |
| Power consumption (typical) | 3.4 W |
| Input current | 1 A |
| DC input voltage | 5 V |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Storage temperature (T-T) | -10 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Heat dissipation | 13 BTU/h |
| Weight & dimensions | |
| Width | 168 mm |
| Depth | 100 mm |
| Height | 29 mm |
| Weight | 175 g |
| Packaging data | |
| AC adapter included | Yes |
| Packaging content | |
| AC adapter included | Yes |
| Marca | Planet |
|---|---|
| MPN: | GSD-804 |
