Zyxel NWA1123-ACPRO access point interior 1 puerto lan rj45 10 100 1000 mbps mimo 3x3 2.4ghz 450mbps 5ghz 1300mbps wifi 802.11ac administrable con nebula alimentación poe at (inyector incluido)
Precio especial $2,335.00 IVA incluido + Envio $150 MXN
Antes $2,709.00
Disponible 23 Pzas
Antes $2,709.00
Disponible 23 Pzas
sku: NWA1123-ACPRO
pub
MX0000085662
Wireless frequency | 2.4 GHz & 5 GHz |
Radio | 2 |
Especificaciones RF | |
Frequency band | 2.4 GHz (802.11 b/g/n)
5 GHz (802.11 a/n/ac)
|
802.11 premium features |
|
Typical transmit output power (dBm) *1 | US (FCC) 2.4 GHz : 27 US (FCC) 5 GHz : 27 EU (ETSI) 2.4 GHz : 18 EU (ETSI) 5 GHz : 24 |
Number of antenna | 3T3R MIMO |
Antenna gain | 2.4 GHz :
5 GHz :
|
Support data rate |
|
Receive sensitivity | Min. Rx sensitivity to -102 dBm |
LAN | |
Number of 10/100/1000M LAN | 2 |
PoE | Yes |
PoE power draw | 12.48 W (802.3at PoE)*2 |
WLAN Security | |
WEP | Yes |
WPA/WPA2-PSK | Yes |
WPA/WPA2-Enterprise | Yes |
EAP type | EAP-TLS, EAP-TTLS, EAP-PEAP, EAP-FAST, EAP-AKA and EAP-SIM |
WMM | WiFi compliant |
IEEE 802.1X | Yes |
Number of multiple SSID | 16 |
MAC filtering | Yes |
L2 Isolation | Yes, multiple profile |
RADIUS authentication | Yes |
Network | |
IPv6 support | Yes |
VLANs | Yes |
DHCP client | Yes |
Zyxel One Network | |
ZON Utility |
|
Management | |
Zyxel AP Configurator*2 |
|
Standalone AP mode | Yes |
CLI | Yes, SSH |
SNMP | Yes |
Others | |
Plenum rating | Yes |
Power supply | 802.3at PoE only (No DC jack) |
MTBF (hr) | 1,005,235 |
Standard Compliance | |
Ethernet |
|
WLAN |
|
Certifications | |
Radio |
|
EMC |
|
Safety |
|
Physical Specifications and others | |
Item | Dimensions (WxDxH)(mm/in.) 203.9 x 191.7 x 34.7/8.03 x 7.55 x 1.37 Weight (g/lb.) 445/0.98 |
Packing | Dimensions (WxDxH)(mm/in.) 240 x 235 x 100/9.45 x 9.25 x 3.94 Weight (g/lb.) 1210/2.67 |
Included accessories |
|
Environmental Specifications | |
Operating | Temperature 0°C to 50°C/32°F to 122°F Humidity 10% to 90% (non-condensing) |
Storage | Temperature -40°C to 70°C/-40°F to 158°F Humidity 10% to 90% |
Notes:
*1: Maximum output power is limited by regional regulatory.
*2: Support from ZAC Utility V1.1.3 or above.
Marca | Zyxel |
---|---|
MPN: | NWA1123-ACPRO |
